Yealink SIP-T53W Auto Provisioning Guide

Obtaining the Provisioning Server Address
31
Obtaining the Provisioning Server Address
Yealink IP phones can obtain the provisioning server address in the following ways:
 Zero Touch
 Plug and Play (PnP) Server
 DHCP Options
 Phone Flash
 Configuring Wildcard of the Provisioning Server URL
The priority of obtaining the provisioning server address is as follows: Zero Touch>PnP
Server>DHCP Options (for IPv4: IPv4 Custom option>option 66>option 43; for IPv6: IPv6
Custom option>option 59) >Phone Flash. The following sections detail the process of each way
(take the SIP-T23G IP phone as an example).
Zero Touch
Zero Touch allows you to configure the network parameters and provisioning server address via
phone user interface during startup. This feature is helpful when there is a system failure on the
IP phone. To use Zero Touch, make sure this feature is enabled. This feature is not applicable to
W52P/W53P/W56P/W60P/CP930W-Base IP phones.
To configure zero touch via web user interface:
1. Click on Settings->Auto Provision.
2. Select Enabled from the pull-down list of Zero Active.
3. Enter the desired waiting time in the Wait Time(1~100s) field.
IPv6 custom option is only applicable to SIP-T54W, SIP-T54S, SIP-T53W, SIP-T53, SIP-T52S,
SIP-T48G/S, SIP-T46G/S, SIP-T42G/S, SIP-T41P/S, SIP-T40P/G, SIP-T29G, SIP-T27G, SIP-T23P/G,
SIP-T21(P) E2 and SIP-T19(P) E2 IP phones running firmware version 83 or later.

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
