Yealink SIP-T53W Auto Provisioning Guide

Introduction
1
Introduction
Yealink IP phones are full-featured telephones that can be plugged directly into an IP network
and can be used easily without manual configuration.
This guide provides instructions on how to provision Yealink IP phones with the minimum
settings required. Yealink IP phones support FTP, TFTP, HTTP, and HTTPS protocols for auto
provisioning and are configured by default to use the TFTP protocol.
Supported Phones
The purpose of this guide is to serve as a basic guidance for provisioning Yealink IP phones.
The following table lists product names and available firmware versions for IP phones that use
auto provisioning process outlined in this guide.
Product Name
Boot File
(Available Firmware
Version)
Exclude Mode
(Available Firmware
Version)
VP59
Yes (83 or later)
Yes (83 or later)
SIP-T58A
Yes (80 or later)
Yes (83 or later)
SIP-T54W
Yes (84 or later)
Yes (84 or later)
SIP-T54S
Yes (81 or later)
Yes (83 or later)
SIP-T53W/T53
Yes (84 or later)
Yes (84 or later)
SIP-T52S
Yes (81 or later)
Yes (83 or later)
SIP-T48G/S
Yes (81 or later)
Yes (83 or later)
SIP-T46G/S
Yes (81 or later)
Yes (83 or later)
SIP-T42G/S
Yes (81 or later)
Yes (83 or later)
SIP-T41P/S
Yes (81 or later)
Yes (83 or later)
SIP-T40P/G
Yes (81 or later)
Yes (83 or later)
SIP-T29G
Yes (81 or later)
Yes (83 or later)
SIP-T27G
Yes (81 or later)
Yes (83 or later)
SIP-T23P/G
Yes (81 or later)
Yes (83 or later)
SIP-T21(P) E2
Yes (81 or later)
Yes (83 or later)
SIP-T19(P) E2
Yes (81 or later)
Yes (83 or later)

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
