YORK INTERNATIONAL
40
SWSI (AF) PLENUM FANS
UNIT
FAN MAX MAX MOTOR MAXIMUM FAN
SIZE
SEGMENT NO. TYPE SIZE MOTOR HP FRAME TSP RPM
65 1 BI 15 3 182T 3 2762
85 1 BI 15 3 182T 3 2762
105 1 BI 15 5 184T 3 2762
125 1 AF 18 5 184T 3 2294
170 1 AF 20 7.5 213T 3 2093
215 1 AF 24 10 215T 3 1708
250 1 AF 27 10 215T 3 1558
305 1 AF 30 15 254T 3 1402
350 1 AF 33 15 254T 3 1275
400 1 AF 36 15 254T 3 1071
460 1 AF 36 20 256T 3 1071
530 1 AF 40 20 256T 3 971
680 1 AF 49 30 286T 3 797
860 1 AF 49 30 286T 3 797
1030 1 AF 49 40 324T 3 797
TABLE 7 – PLENUM RETURN FAN AND MOTOR DATA – FP(V) ECONOMIZER
NOTE: 1. Units with SWSI fans are not within the scope of ARI Certification (Standard 430). 2. RPM based on Class II fans
3. All plenum fans will be Class II
