York HB360 User Manual

036-21345-001-B-0105
Unitary Products Group 11
TABLE 11: COOLING CAPACITY 40/40 TON UNIT - HB480 CONDENSING UNIT MATCHED WITH LB480 EVAPORATOR UNIT
AIR ON
EVAP. COIL
TEMPERATURE OF AIR ON CONDENSER COIL 85ºF
AIR ON
EVAP. COIL
TEMPERATURE OF AIR ON CONDENSER COIL 95ºF
CFM
WB
(ºF)
GROSS
CAPACITY
(MBH)
TOTAL
INPUT
(Kw)
GROSS SENSIBLE CAPACITY (MBh) RETURN DRY BULB
(ºF)
CFM
WB
(ºF)
GROSS
CAPACITY
(MBH)
TOTAL
INPUT
(Kw)
GROSS SENSIBLE CAPACITY (MBh) RETURN DRY BULB
(ºF)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
12000
72 490.0 42.38 321.1 282.2 243.3 204.5 165.6 #N/A #N/A
12000
72 469.3 45.98 313.3 274.4 235.5 196.6 157.8 #N/A #N/A
67 460.7 41.53 400.9 362.0 323.2 284.3 245.4 206.5 167.6 67 442.3 45.19 393.2 354.3 315.4 276.5 237.6 198.8 159.9
62 452.0 41.39 452.0 447.3 408.5 369.6 330.7 291.8 252.9 62 435.4 45.10 435.4 430.9 392.0 353.1 314.3 275.4 236.5
57 451.4 41.25 451.4 446.8 407.9 369.1 330.2 291.3 252.4 57 434.8 44.93 434.8 430.4 391.5 352.6 313.7 274.9 236.0
14000
72 500.2 42.63 352.6 307.3 261.9 216.6 171.2 #N/A #N/A
14000
72 479.4 46.25 344.9 299.5 254.1 208.8 163.4 #N/A #N/A
67 470.3 41.78 438.6 393.2 347.8 302.5 257.1 211.8 166.4 67 451.8 45.46 427.2 385.7 340.3 295.0 249.6 204.3 158.9
62 461.4 41.63 461.4 459.1 439.7 394.3 349.0 303.6 258.2 62 444.7 45.36 444.7 442.5 423.0 377.7 332.3 286.9 241.6
57 460.8 41.50 460.8 458.5 439.1 393.7 348.4 303.0 257.7 57 444.1 45.19 444.1 441.9 422.5 377.1 331.7 286.4 241.0
16000
72 510.4 42.88 384.2 332.4 280.5 228.7 176.8 #N/A #N/A
16000
72 489.4 46.52 376.5 324.6 272.8 220.9 169.1 #N/A #N/A
67 479.9 42.02 476.2 424.4 372.5 320.7 268.9 217.0 165.2 67 461.2 45.72 461.2 417.1 365.3 313.4 261.6 209.8 157.9
62 470.9 41.88 470.9 470.9 470.9 419.0 367.2 315.4 263.5 62 454.0 45.62 454.0 454.0 454.0 402.2 350.3 298.5 246.7
57 470.3 41.74 470.3 470.3 470.3 418.4 366.6 314.7 262.9 57 453.4 45.45 453.4 453.4 453.4 401.6 349.7 297.9 246.0
18000
72 517.9 43.10 414.4 356.1 297.8 239.5 181.2 #N/A #N/A
18000
72 496.0 46.71 406.2 347.9 289.6 231.3 173.0 #N/A #N/A
67 486.9 42.24 485.1 453.8 395.5 337.2 278.8 220.5 162.2 67 467.4 45.90 467.4 445.4 387.8 329.5 271.2 212.8 154.5
62 477.8 42.10 477.8 477.8 477.8 419.5 361.1 302.8 244.5 62 460.1 45.81 460.1 460.1 460.1 401.8 343.5 285.2 226.9
57 477.2 41.96 477.2 477.2 477.2 418.8 360.5 302.2 243.9 57 459.5 45.63 459.5 459.5 459.5 401.2 342.9 284.6 226.2
20000
72 525.4 43.32 444.7 379.9 315.1 250.3 185.5 #N/A #N/A
20000
72 502.6 46.89 436.0 371.2 306.4 241.6 176.8 #N/A #N/A
67 494.0 42.46 494.0 483.2 418.4 353.6 288.8 224.0 159.2 67 473.7 46.09 473.7 473.7 410.3 345.5 280.7 215.9 151.1
62 484.7 42.31 484.7 484.7 484.7 419.9 355.1 290.3 225.5 62 466.2 45.99 466.2 466.2 466.2 401.4 336.6 271.8 207.0
57 484.0 42.17 484.0 484.0 484.0 419.2 354.4 289.6 224.8 57 465.6 45.82 465.6 465.6 465.6 400.8 336.0 271.2 206.4
TEMPERATURE OF AIR ON CONDENSER COIL 105ºF TEMPERATURE OF AIR ON CONDENSER COIL 115ºF
12000
72 448.8 50.43 306.2 267.3 228.5 189.6 150.7 #N/A #N/A
12000
72 428.2 54.87 299.2 260.3 221.4 182.5 143.6 #N/A #N/A
67 423.3 49.66 385.5 346.7 307.8 268.9 230.0 191.1 152.3 67 404.2 54.14 377.9 339.1 300.2 261.3 222.4 183.5 144.7
62 418.8 49.67 418.8 415.4 376.5 337.6 298.7 259.9 221.0 62 402.1 54.24 402.1 399.9 361.0 322.1 283.2 244.3 205.5
57 418.3 49.46 418.3 414.9 376.0 337.2 298.3 259.4 220.5 57 401.7 53.99 401.7 399.5 360.6 321.7 282.8 244.0 205.1
14000
72 458.1 50.70 337.3 291.9 246.6 201.2 155.9 #N/A #N/A
14000
72 436.8 55.14 329.7 284.4 239.0 193.7 148.3 #N/A #N/A
67 432.1 49.93 413.2 377.5 332.2 286.8 241.5 196.1 150.7 67 412.4 54.40 399.2 369.4 324.0 278.7 233.3 188.0 142.6
62 427.5 49.93 427.5 425.8 406.4 361.0 315.6 270.3 224.9 62 410.3 54.50 410.3 409.1 389.7 344.3 299.0 253.6 208.2
57 427.0 49.72 427.0 425.3 405.9 360.5 315.1 269.8 224.4 57 409.8 54.26 409.8 408.7 389.3 343.9 298.5 253.2 207.8
16000
72 467.4 50.97 368.4 316.5 264.7 212.9 161.0 #N/A #N/A
16000
72 445.5 55.41 360.3 308.5 256.6 204.8 152.9 #N/A #N/A
67 440.9 50.19 440.9 408.4 356.6 304.8 252.9 201.1 149.2 67 420.5 54.67 420.5 399.7 347.9 296.1 244.2 192.4 140.5
62 436.2 50.20 436.2 436.2 436.2 384.4 332.5 280.7 228.8 62 418.4 54.77 418.4 418.4 418.4 366.6 314.7 262.9 211.0
57 435.7 49.99 435.7 435.7 435.7 383.8 332.0 280.2 228.3 57 417.9 54.52 417.9 417.9 417.9 366.1 314.3 262.4 210.6
18000
72 473.6 51.15 398.1 339.8 281.5 223.2 164.9 #N/A #N/A
18000
72 451.2 55.58 390.0 331.7 273.4 215.1 156.8 #N/A #N/A
67 446.7 50.37 446.7 430.4 379.2 320.9 262.6 204.3 146.0 67 425.9 54.84 425.9 415.5 370.7 312.3 254.0 195.7 137.4
62 441.9 50.37 441.9 441.9 441.9 383.6 325.3 267.0 208.7 62 423.7 54.94 423.7 423.7 423.7 365.4 307.1 248.8 190.5
57 441.4 50.16 441.4 441.4 441.4 383.1 324.8 266.4 208.1 57 423.3 54.69 423.3 423.3 423.3 365.0 306.6 248.3 190.0
20000
72 479.7 51.33 427.9 363.1 298.3 233.5 168.7 #N/A #N/A
20000
72 456.9 55.76 419.8 355.0 290.2 225.4 160.6 #N/A #N/A
67 452.5 50.55 452.5 452.5 401.9 337.1 272.3 207.5 142.7 67 431.3 55.01 431.3 431.3 393.4 328.6 263.8 199.0 134.2
62 447.7 50.55 447.7 447.7 447.7 382.9 318.1 253.3 188.5 62 429.1 55.11 429.1 429.1 429.1 364.3 299.5 234.7 169.9
57 447.1 50.34 447.1 447.1 447.1 382.3 317.5 252.7 187.9 57 428.6 54.86 428.6 428.6 428.6 363.8 299.0 234.2 169.4
TEMPERATURE OF AIR ON CONDENSER COIL 125ºF
12000
72 407.6 59.3 292.1 253.2 214.3 175.5 136.6 #N/A #N/A
1
These capacities are gross ratings. For net capacity, deduct air blower motor,
MBH - 3.415 X kW. Refer to the appropriate Blower Performance Table for the
kW of the supply air blower motor.
2
These ratings include condenser fan motors and the compressor motors but not
the supply blower motor.
67 385.1 58.6 370.3 331.4 292.6 253.7 214.8 175.9 137.0
62 385.5 58.8 385.5 384.3 345.5 306.6 267.7 228.8 189.9
57 385.2 58.5 385.2 384.0 345.1 306.3 267.4 228.5 189.6
14000
72 415.6 59.6 322.2 276.8 231.4 186.1 140.7 #N/A #N/A
67 392.6 58.9 385.2 361.2 315.9 270.5 225.2 179.8 134.4
62 393.0 59.1 393.0 392.5 373.0 327.7 282.3 236.9 191.6
57 392.7 58.8 392.7 392.1 372.7 327.3 282.0 236.6 191.2
16000
72 423.5 59.9 352.2 300.4 248.5 196.7 144.9 #N/A #N/A
67 400.2 59.1 400.2 391.1 339.2 287.4 235.5 183.7 131.9
62 400.6 59.3 400.6 400.6 400.6 348.7 296.9 245.1 193.2
57 400.2 59.1 400.2 400.2 400.2 348.4 296.5 244.7 192.8
18000
72 428.8 60.0 381.9 323.6 265.3 207.0 148.7 #N/A #N/A
67 405.1 59.3 405.1 400.6 362.1 303.8 245.4 187.1 128.8
62 405.5 59.5 405.5 405.5 405.5 347.2 288.9 230.6 172.3
57 405.2 59.2 405.2 405.2 405.2 346.8 288.5 230.2 171.9
20000
72 434.0 60.2 411.7 346.9 282.1 217.3 152.5 #N/A #N/A
67 410.1 59.5 410.1 410.1 385.0 320.2 255.4 190.6 125.8
62 410.5 59.7 410.5 410.5 410.5 345.7 280.9 216.1 151.3
57 410.1 59.4 410.1 410.1 410.1 345.3 280.5 215.7 150.9
