036-21345-001-B-0105
Unitary Products Group 9
TABLE 9: COOLING CAPACITY 25 TON UNIT - HA300 CONDENSING UNIT MATCHED WITH LA300 EVAPORATOR UNIT
AIR ON
EVAP. COIL
TEMPERATURE OF AIR ON CONDENSER COIL 85ºF
AIR ON
EVAP. COIL
TEMPERATURE OF AIR ON CONDENSER COIL 95ºF
CFM
WB
(ºF)
GROSS
CAPACITY
(MBH)
TOTAL
INPUT
(Kw)
GROSS SENSIBLE CAPACITY (MBh) RETURN DRY BULB
(ºF)
CFM
WB
(ºF)
GROSS
CAPACITY
(MBH)
TOTAL
INPUT
(Kw)
GROSS SENSIBLE CAPACITY (MBh) RETURN DRY BULB
(ºF)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
7500
72 306.9 26.92 201.5 177.2 152.9 128.6 104.3 #N/A #N/A
7500
72 294.4 29.12 29.12 197.3 173.0 148.7 124.4 100.1 #N/A
67 288.8 26.54 250.2 225.9 201.6 177.3 153.0 128.7 104.4 67 277.2 28.85 245.3 221.0 196.7 172.4 148.1 123.8 99.5
62 278.2 21.44 278.2 275.5 251.2 226.9 202.6 178.3 154.0 62 268.7 28.71 268.7 266.7 242.4 218.1 193.8 169.5 145.2
57 278.0 21.37 278.0 275.3 251.0 226.7 202.4 178.1 153.8 57 268.5 28.70 268.5 266.6 242.3 218.0 193.7 169.4 145.1
8750
72 314.2 27.02 221.9 193.5 165.2 136.8 108.5 #N/A #N/A
8750
72 301.1 29.27 217.2 188.8 160.5 132.1 103.8 #N/A #N/A
67 295.7 26.67 274.5 246.1 217.8 189.4 161.1 132.7 104.4 67 283.5 29.00 267.6 240.7 212.4 184.0 155.7 127.3 99.0
62 284.8 21.52 284.8 283.3 271.1 242.8 214.4 186.1 157.7 62 274.8 28.85 274.8 273.8 261.6 233.3 204.9 176.6 148.2
57 284.6 21.45 284.6 283.3 271.1 242.8 214.4 186.1 157.7 57 274.6 28.85 274.6 273.7 261.5 233.2 204.8 176.4 148.1
10000
72 321.5 27.13 242.2 209.8 177.4 145.0 112.6 #N/A #N/A
10000
72 307.8 29.41 237.1 204.7 172.3 139.9 107.5 #N/A #N/A
67 302.5 26.77 298.7 266.3 233.9 201.5 169.1 136.7 104.3 67 289.8 29.14 289.8 260.4 228.0 195.6 163.2 130.8 98.4
62 291.4 21.60 291.4 291.4 291.4 259.0 226.6 194.2 161.8 62 280.9 29.00 280.9 280.9 280.9 248.5 216.1 183.7 151.3
57 291.2 21.53 291.2 291.2 291.2 258.8 226.4 194.0 161.6 57 280.8 28.99 280.0 280.8 280.8 248.4 216.0 183.6 151.2
11250
72 326.1 27.19 261.3 224.8 188.4 151.9 115.5 #N/A #N/A
11250
72 312.0 29.47 256.1 219.6 183.2 146.7 110.3 #N/A #N/A
67 306.8 26.83 305.0 284.8 248.4 211.9 175.5 139.0 102.6 67 293.8 29.20 293.8 278.9 242.2 206.0 169.5 133.1 96.6
62 295.6 21.65 295.6 295.6 295.6 259.1 222.7 186.2 149.8 62 284.8 29.06 284.8 284.8 284.8 248.3 211.9 175.4 139.0
57 295.4 21.58 295.4 295.4 295.4 259.0 222.5 186.1 149.6 57 284.6 29.05 284.6 284.6 284.6 248.2 211.7 175.3 138.8
12500
72 330.7 27.25 280.3 239.8 199.3 158.8 118.3 #N/A #N/A
12500
72 316.2 29.54 275.1 234.6 184.1 153.6 113.1 #N/A #N/A
67 311.2 26.90 311.2 303.3 262.8 222.3 181.8 141.3 100.8 67 297.8 29.26 297.8 297.3 256.8 216.3 175.8 135.3 94.8
62 299.7 21.70 299.7 299.7 299.7 259.2 218.7 178.2 137.7 62 288.6 29.12 288.6 288.6 288.6 248.1 207.6 167.1 126.6
57 299.6 21.64 299.6 299.6 299.6 259.1 218.6 178.1 137.6 57 288.5 29.11 288.5 288.5 288.5 248.0 207.5 167.0 126.5
TEMPERATURE OF AIR ON CONDENSER COIL 105ºF TEMPERATURE OF AIR ON CONDENSER COIL 115ºF
7500
72 280.5 32.04 191.8 167.5 143.2 118.9 94.6 #N/A #N/A
7500
72 266.7 34.96 186.4 162.1 137.8 113.5 89.2 #N/A #N/A
67 264.9 31.78 240.2 215.9 191.6 167.3 143.0 118.7 94.4 67 252.7 34.70 235.0 210.7 186.4 162.1 137.8 113.5 89.2
62 258.3 31.72 258.3 256.5 232.2 207.9 183.6 159.3 135.0 62 247.8 34.73 247.8 246.3 222.0 197.7 173.4 149.1 124.8
57 258.1 31.71 258.1 256.4 232.1 207.8 183.5 159.2 134.9 57 247.7 34.72 247.7 246.1 221.8 197.5 173.2 148.9 124.6
8750
72 286.7 32.17 211.5 183.1 154.8 126.4 98.1 #N/A #N/A
8750
72 272.4 35.07 205.8 177.5 149.1 120.8 92.4 #N/A #N/A
67 270.8 31.90 258.5 235.5 207.1 178.8 150.4 122.1 93.7 67 258.2 34.81 249.3 230.2 201.8 173.5 145.1 116.8 88.4
62 264.0 31.84 264.0 263.1 251.0 222.6 194.3 165.9 137.6 62 253.2 34.83 253.2 252.4 240.3 211.9 183.6 155.2 126.9
57 263.9 31.84 263.9 263.0 250.8 222.5 194.1 165.8 137.4 57 253.1 34.83 253.1 252.3 240.2 211.8 183.5 155.1 126.8
10000
72 293.0 32.30 231.2 198.8 166.4 134.0 101.6 #N/A #N/A
10000
72 278.2 35.18 225.3 192.9 160.5 128.1 95.7 #N/A #N/A
67 276.7 32.03 276.7 255.0 222.6 190.2 157.8 125.4 93.0 67 263.6 34.92 263.6 249.6 217.2 184.8 152.4 120.0 87.6
62 269.7 31.97 269.7 269.7 269.7 237.3 204.9 172.5 140.1 62 258.6 34.94 258.6 258.6 258.6 226.2 193.8 161.4 129.0
57 269.6 31.97 269.6 269.6 269.6 237.2 204.8 172.4 140.0 57 258.5 34.94 258.5 258.5 258.5 226.1 193.7 161.3 128.9
11250
72 296.9 32.39 250.1 213.6 177.2 140.7 104.3 #N/A #N/A
11250
72 281.9 35.31 244.1 207.6 171.2 134.7 98.3 #N/A #N/A
67 280.5 32.12 280.5 269.5 237.1 200.6 164.2 127.7 91.3 67 267.1 35.04 267.1 260.1 231.7 195.2 158.8 122.3 85.9
62 273.4 32.06 273.4 273.4 273.4 236.9 200.5 164.0 127.6 62 262.0 35.07 262.0 262.0 262.0 225.6 189.1 152.7 116.2
57 273.3 32.06 273.3 273.3 273.3 236.8 200.4 163.9 127.5 57 261.9 35.07 261.9 261.9 261.9 225.4 189.0 152.5 116.1
12500
72 300.9 32.49 269.0 228.5 188.0 147.5 107.0 #N/A #N/A
12500
72 285.6 35.44 262.9 222.4 181.9 141.4 100.9 #N/A #N/A
67 284.2 32.22 284.2 284.0 251.5 211.0 170.5 130.0 89.5 67 270.6 35.17 270.6 270.6 246.2 205.7 165.2 124.7 84.2
62 277.0 32.15 277.0 277.0 277.0 236.5 196.0 155.5 115.0 62 265.5 35.19 265.5 265.5 265.5 225.0 184.5 144.0 103.5
57 276.9 32.15 276.9 276.9 276.9 236.4 195.9 155.4 114.9 57 265.3 35.19 265.3 265.3 265.3 224.8 184.3 143.8 103.3
TEMPERATURE OF AIR ON CONDENSER COIL 125ºF
7500
72 252.8 37.9 180.9 156.6 132.3 108.0 83.7 #N/A #N/A
1
These capacities are gross ratings. For net capacity, deduct air blower motor,
MBH - 3.415 X kW. Refer to the appropriate Blower Performance Table for the
kW of the supply air blower motor.
2
These ratings include condenser fan motors and the compressor motors but not
the supply blower motor.
67 240.4 37.6 229.9 205.6 181.3 157.0 132.7 108.4 84.1
62 237.4 37.7 237.4 236.0 211.7 187.4 163.1 138.8 114.5
57 237.3 37.7 237.3 235.9 211.6 187.3 163.0 138.7 114.4
8750
72 258.1 38.0 200.1 171.8 143.4 115.1 86.7 #N/A #N/A
67 245.5 37.7 240.2 224.9 196.5 168.2 139.8 111.5 83.1
62 242.4 37.8 242.4 241.7 229.6 201.2 172.9 144.5 116.2
57 242.3 37.8 242.3 241.6 229.5 201.1 172.8 144.4 116.1
10000
72 263.4 38.1 219.4 187.0 154.6 122.2 89.8 #N/A #N/A
67 250.5 37.8 250.5 244.2 211.8 179.4 147.0 114.6 82.2
62 247.4 37.9 247.4 247.4 247.4 215.0 182.6 150.2 117.8
57 247.3 37.9 247.3 247.3 247.3 214.9 182.5 150.1 117.7
11250
72 266.9 38.2 238.1 201.6 165.2 128.7 92.3 #N/A #N/A
67 253.8 38.0 253.8 250.7 226.3 189.9 153.4 117.0 80.5
62 250.6 38.1 250.6 250.6 250.6 214.2 177.7 141.3 104.8
57 250.5 38.1 250.5 250.5 250.5 214.1 177.6 141.2 104.7
12500
72 270.3 38.4 256.8 216.3 175.8 135.3 94.8 #N/A #N/A
67 257.1 38.1 257.1 257.1 240.8 200.3 159.8 119.3 78.8
62 253.9 38.2 253.9 253.9 253.9 213.4 172.9 132.4 91.9
57 253.8 38.2 253.8 253.8 253.8 213.3 172.8 132.3 91.8
To Next Page
