York HB360 User Manual

036-21345-001-B-0105
12 Unitary Products Group
TABLE 12: COOLING CAPACITY 40/50 TON UNIT - HB480 CONDENSING UNIT MATCHED WITH LB600 EVAPORATOR UNIT
AIR ON
EVAP. COIL
TEMPERATURE OF AIR ON CONDENSER COIL 85ºF
AIR ON
EVAP. COIL
TEMPERATURE OF AIR ON CONDENSER COIL 95ºF
CFM
WB
(ºF)
GROSS
CAPACITY
(MBH)
TOTAL
INPUT
(Kw)
GROSS SENSIBLE CAPACITY (MBh) RETURN DRY BULB
(ºF)
CFM
WB
(ºF)
GROSS
CAPACITY
(MBH)
TOTAL
INPUT
(Kw)
GROSS SENSIBLE CAPACITY (MBh) RETURN DRY BULB
(ºF)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
12000
72 495.6 42.77 324.4 285.5 246.6 207.7 168.9 #N/A #N/A
12000
72 475.6 46.17 318.5 279.6 240.7 201.8 162.9 #N/A #N/A
67 468.4 41.84 405.3 366.4 327.5 288.6 249.7 210.9 172.0 67 449.9 45.39 398.6 359.7 320.8 281.9 243.1 204.2 165.3
62 453.9 41.52 453.9 447.7 408.8 369.9 331.0 292.1 253.3 62 438.2 45.16 438.2 433.6 394.7 355.8 316.9 278.1 239.2
57 453.7 41.51 453.7 447.5 408.6 369.7 330.8 291.9 253.1 57 438.0 45.16 438.0 433.4 394.5 355.6 316.8 277.9 239.0
14000
72 506.7 43.00 357.1 311.7 266.4 221.0 175.6 #N/A #N/A
14000
72 485.8 46.45 350.5 305.1 259.8 214.4 169.0 #N/A #N/A
67 478.8 42.07 444.4 399.1 353.7 308.4 263.0 217.6 172.3 67 459.7 45.66 434.0 391.6 346.2 300.9 255.5 210.1 164.8
62 464.1 41.74 464.1 460.9 441.5 396.1 350.8 305.4 260.1 62 447.7 45.43 447.7 445.4 425.9 380.6 335.2 289.9 244.5
57 463.9 41.74 463.9 460.7 441.3 395.9 350.6 305.2 259.9 57 447.5 45.43 447.5 445.2 425.7 380.4 335.0 289.7 244.3
16000
72 517.8 43.24 389.8 337.9 286.1 234.3 182.4 #N/A #N/A
16000
72 496.1 46.73 382.5 330.6 278.8 227.0 175.1 #N/A #N/A
67 489.3 42.29 483.6 431.8 379.9 328.1 276.3 224.4 172.6 67 469.4 45.93 469.4 423.4 371.6 319.8 267.9 216.1 164.2
62 474.2 41.96 474.2 474.2 474.2 422.4 370.5 318.7 266.9 62 457.2 45.70 457.2 457.2 457.2 405.3 353.5 301.7 249.8
57 474.0 41.96 474.0 474.0 474.0 422.2 370.3 318.5 266.6 57 457.0 45.70 457.0 457.0 457.0 405.1 353.3 301.4 249.6
18000
72 524.8 43.42 420.3 361.9 303.6 245.3 187.0 #N/A #N/A
18000
72 502.5 46.90 412.7 354.3 296.0 237.7 179.4 #N/A #N/A
67 495.9 42.48 493.1 461.5 403.2 344.9 286.6 228.2 169.9 67 475.4 46.10 475.4 452.5 394.5 336.2 277.9 219.6 161.3
62 480.6 42.15 480.6 480.6 480.6 422.3 364.0 305.6 247.3 62 463.1 45.87 463.1 463.1 463.1 404.7 346.4 288.1 229.8
57 480.4 42.14 480.4 480.4 480.4 422.1 363.7 305.4 247.1 57 462.9 45.87 462.9 462.9 462.9 404.5 346.2 287.9 229.6
20000
72 531.8 43.61 450.7 385.9 321.1 256.3 191.5 #N/A #N/A
20000
72 508.9 47.07 442.8 378.0 313.2 248.4 183.6 #N/A #N/A
67 502.5 42.66 502.5 491.2 426.4 361.6 296.8 232.0 167.2 67 481.5 46.27 481.5 481.5 417.5 352.7 287.9 223.1 158.3
62 487.0 42.33 487.0 487.0 487.0 422.2 357.4 292.6 227.8 62 469.0 46.04 469.0 469.0 469.0 404.2 339.4 274.6 209.8
57 486.8 42.33 486.8 486.8 486.8 422.0 357.2 292.4 227.6 57 468.7 46.04 468.7 468.7 468.7 403.9 339.1 274.3 209.5
TEMPERATURE OF AIR ON CONDENSER COIL 105ºF TEMPERATURE OF AIR ON CONDENSER COIL 115ºF
12000
72 454.8 50.64 311.0 272.1 233.3 194.4 155.5 #N/A #N/A
12000
72 434.0 55.10 303.6 264.7 225.8 186.9 148.0 #N/A #N/A
67 430.3 49.87 390.3 351.4 312.6 273.7 234.8 195.9 157.0 67 410.6 54.35 382.1 343.2 304.3 265.4 226.5 187.7 148.8
62 421.6 49.65 421.6 418.2 379.3 340.4 301.6 262.7 223.8 62 405.0 54.13 405.0 402.8 363.9 325.1 286.2 247.3 208.4
57 421.4 49.64 421.4 418.0 379.1 340.3 301.4 262.5 223.6 57 404.8 54.13 404.8 402.7 363.8 324.9 286.0 247.1 208.3
14000
72 464.2 50.96 342.4 297.0 251.7 206.3 160.9 #N/A #N/A
14000
72 442.7 55.47 334.3 288.9 243.6 198.2 152.8 #N/A #N/A
67 439.3 50.18 419.3 382.6 337.2 291.9 246.5 201.1 155.8 67 418.9 54.71 404.6 373.6 328.2 282.9 237.5 192.1 146.8
62 430.4 49.96 430.4 428.7 409.2 363.9 318.5 273.2 227.8 62 413.1 54.49 413.1 412.0 392.5 347.2 301.8 256.5 211.1
57 430.2 49.96 430.2 428.5 409.1 363.7 318.3 273.0 227.6 57 412.9 54.48 412.9 411.8 392.4 347.0 301.6 256.3 210.9
16000
72 473.7 51.28 373.7 321.9 270.1 218.2 166.4 #N/A #N/A
16000
72 451.3 55.83 365.0 313.1 261.3 209.5 157.6 #N/A #N/A
67 448.2 50.50 448.2 413.7 361.9 310.0 258.2 206.4 154.5 67 427.1 55.06 427.1 404.0 352.1 300.3 248.5 196.6 144.8
62 439.2 50.28 439.2 439.2 439.2 387.3 335.5 283.6 231.8 62 421.2 54.85 421.2 421.2 421.2 369.3 317.5 265.6 213.8
57 439.0 50.27 439.0 439.0 439.0 387.1 335.3 283.4 231.6 57 421.0 54.84 421.0 421.0 421.0 369.1 317.3 265.4 213.6
18000
72 479.7 51.45 404.1 345.8 287.4 229.1 170.8 #N/A #N/A
18000
72 457.0 56.00 395.5 337.2 278.9 220.5 162.2 #N/A #N/A
67 453.9 50.67 453.9 436.7 385.2 326.9 268.5 210.2 151.9 67 432.4 55.23 432.4 420.9 375.8 317.5 259.2 200.9 142.5
62 444.7 50.44 444.7 444.7 444.7 386.4 328.1 269.8 211.5 62 426.4 55.01 426.4 426.4 426.4 368.1 309.8 251.4 193.1
57 444.5 50.44 444.5 444.5 444.5 386.2 327.9 269.6 211.3 57 426.2 55.01 426.2 426.2 426.2 367.9 309.6 251.3 192.9
20000
72 485.8 51.62 434.4 369.6 304.8 240.0 175.2 #N/A #N/A
20000
72 462.6 56.16 426.0 361.2 296.4 231.6 166.8 #N/A #N/A
67 459.6 50.83 459.6 459.6 408.5 343.7 278.9 214.1 149.3 67 437.7 55.40 437.7 437.7 399.5 334.7 269.9 205.1 140.3
62 450.3 50.61 450.3 450.3 450.3 385.5 320.7 255.9 191.1 62 431.7 55.18 431.7 431.7 431.7 366.9 302.1 237.3 172.5
57 450.1 50.60 450.1 450.1 450.1 385.3 320.5 255.7 190.9 57 431.5 55.17 431.5 431.5 431.5 366.7 301.9 237.1 172.3
TEMPERATURE OF AIR ON CONDENSER COIL 125ºF
12000
72 413.2 59.6 296.1 257.2 218.4 179.5 140.6 #N/A #N/A
1
These capacities are gross ratings. For net capacity, deduct air blower motor,
MBH - 3.415 X kW. Refer to the appropriate Blower Performance Table for the
kW of the supply air blower motor.
2
These ratings include condenser fan motors and the compressor motors but not
the supply blower motor.
67 391.0 58.8 373.8 334.9 296.0 257.2 218.3 179.4 140.5
62 388.3 58.6 388.3 387.4 348.6 309.7 270.8 231.9 193.0
57 388.1 58.6 388.1 387.3 348.4 309.5 270.6 231.8 192.9
14000
72 421.1 60.0 326.2 280.8 235.5 190.1 144.7 #N/A #N/A
67 398.4 59.2 389.9 364.6 319.2 273.9 228.5 183.1 137.8
62 395.7 59.0 395.7 395.3 375.8 330.5 285.1 239.8 194.4
57 395.6 59.0 395.6 395.1 375.7 330.3 285.0 239.6 194.2
16000
72 428.9 60.4 356.2 304.4 252.5 200.7 148.9 #N/A #N/A
67 405.9 59.6 405.9 394.2 342.4 290.6 238.7 186.9 135.0
62 403.1 59.4 403.1 403.1 403.1 351.3 299.5 247.6 195.8
57 403.0 59.4 403.0 403.0 403.0 351.1 299.3 247.4 195.6
18000
72 434.2 60.5 386.9 328.6 270.3 212.0 153.7 #N/A #N/A
67 410.9 59.8 410.9 405.0 366.5 308.1 249.8 191.5 133.2
62 408.1 59.6 408.1 408.1 408.1 349.8 291.4 233.1 174.8
57 407.9 59.6 407.9 407.9 407.9 349.6 291.3 232.9 174.6
20000
72 439.4 60.7 417.6 352.8 288.0 223.2 158.4 #N/A #N/A
67 415.8 60.0 415.8 415.8 390.5 325.7 260.9 196.1 131.3
62 413.0 59.7 413.0 413.0 413.0 348.2 283.4 218.6 153.8
57 412.8 59.7 412.8 412.8 412.8 348.0 283.2 218.4 153.6
