York HB360 User Manual

036-21345-001-B-0105
Unitary Products Group 13
TABLE 13: COOLING CAPACITY 50 TON UNIT - HB600 CONDENSING UNIT MATCHED WITH LB600 EVAPORATOR UNIT
AIR ON
EVAP. COIL
TEMPERATURE OF AIR ON CONDENSER COIL 85ºF
AIR ON
EVAP. COIL
TEMPERATURE OF AIR ON CONDENSER COIL 95ºF
CFM
WB
(ºF)
GROSS
CAPACITY
(MBH)
TOTAL
INPUT
(Kw)
GROSS SENSIBLE CAPACITY (MBh) RETURN DRY BULB
(ºF)
CFM
WB
(ºF)
GROSS
CAPACITY
(MBH)
TOTAL
INPUT
(Kw)
GROSS SENSIBLE CAPACITY (MBh) RETURN DRY BULB
(ºF)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
15000
72 602.0 49.42 397.9 349.3 300.7 252.1 203.5 #N/A #N/A
15000
72 577.4 54.08 388.9 340.3 291.7 243.1 194.5 #N/A #N/A
67 566.3 48.79 497.3 448.7 400.1 351.5 302.9 254.3 205.7 67 543.9 53.46 487.8 439.2 390.6 342.0 293.4 244.8 196.2
62 555.2 48.68 555.2 551.6 503.0 454.4 405.8 357.2 308.6 62 535.3 53.26 535.3 532.1 483.5 434.9 386.3 337.7 289.1
57 554.4 48.53 554.4 550.9 502.3 453.7 405.1 356.5 307.9 57 535.0 53.25 535.0 531.9 483.3 434.7 386.1 337.5 288.9
17500
72 615.7 49.65 437.2 380.5 323.8 267.1 210.4 #N/A #N/A
17500
72 590.3 54.31 427.9 371.2 314.5 257.8 201.1 #N/A #N/A
67 579.2 49.02 544.3 487.6 430.9 374.2 317.5 260.8 204.1 67 556.0 53.68 528.0 477.9 421.2 364.5 307.8 251.1 194.4
62 567.8 48.91 567.8 566.0 541.7 485.0 428.3 371.6 314.9 62 547.2 53.48 547.2 545.6 521.3 464.6 407.9 351.2 294.5
57 567.0 48.76 567.0 565.2 540.9 484.2 427.5 370.8 314.1 57 546.9 53.47 546.9 545.3 521.0 464.3 407.6 350.9 294.2
20000
72 629.3 49.89 476.6 411.8 347.0 282.2 217.4 #N/A #N/A
20000
72 603.1 54.53 466.9 402.1 337.3 272.5 207.7 #N/A #N/A
67 592.0 49.26 591.3 526.5 461.7 396.9 332.1 267.3 202.5 67 568.1 53.90 568.1 516.5 451.7 386.9 322.1 257.3 192.5
62 580.4 49.14 580.4 580.4 580.4 515.6 450.8 386.0 321.2 62 559.1 53.70 559.1 559.1 559.1 494.3 429.5 364.7 299.9
57 579.6 48.99 579.6 579.6 579.6 514.8 450.0 385.2 320.4 57 558.8 53.69 558.8 558.8 558.8 494.0 429.2 364.4 299.6
22500
72 638.4 50.03 513.5 440.6 367.7 294.8 221.9 #N/A #N/A
22500
72 611.5 54.67 503.7 430.8 357.9 285.0 212.1 #N/A #N/A
67 600.6 49.40 600.2 562.3 489.4 416.5 343.6 270.7 197.8 67 575.9 54.04 575.9 550.2 479.3 406.4 333.5 260.6 187.7
62 588.8 49.29 588.8 588.8 588.8 515.9 443.0 370.1 297.2 62 566.8 53.84 566.8 566.8 566.8 493.9 421.0 348.1 275.2
57 587.9 49.13 587.9 587.9 587.9 515.0 442.1 369.2 296.3 57 566.6 53.83 566.6 566.6 566.6 493.7 420.8 347.9 275.0
25000
72 647.5 50.18 550.5 469.5 388.5 307.5 226.5 #N/A #N/A
25000
72 619.8 54.81 540.5 459.5 378.5 297.5 216.5 #N/A #N/A
67 609.1 49.54 609.1 598.0 517.0 436.0 355.0 274.0 193.0 67 583.8 54.18 583.8 583.8 506.9 425.9 344.9 263.9 182.9
62 597.1 49.43 597.1 597.1 597.1 516.1 435.1 354.1 273.1 62 574.6 53.97 574.6 574.6 574.6 493.6 412.6 331.6 250.6
57 596.3 49.27 596.3 596.3 596.3 515.3 434.3 353.3 272.3 57 574.3 53.97 574.3 574.3 574.3 493.3 412.3 331.3 250.3
TEMPERATURE OF AIR ON CONDENSER COIL 105ºF TEMPERATURE OF AIR ON CONDENSER COIL 115ºF
15000
72 551.5 60.04 379.6 331.0 282.4 233.8 185.2 #N/A #N/A
15000
72 525.7 65.99 370.3 321.7 273.1 224.5 175.9 #N/A #N/A
67 520.1 59.40 477.9 429.3 380.7 332.1 283.5 234.9 186.3 67 496.3 65.34 468.0 419.4 370.8 322.2 273.6 225.0 176.4
62 514.8 59.38 514.8 512.3 463.7 415.1 366.5 317.9 269.3 62 494.3 65.51 494.3 492.6 444.0 395.4 346.8 298.2 249.6
57 514.5 59.38 514.5 512.1 463.5 414.9 366.3 317.7 269.1 57 494.0 65.50 494.0 492.4 443.8 395.2 346.6 298.0 249.4
17500
72 563.6 60.27 418.1 361.4 304.7 248.0 191.3 #N/A #N/A
17500
72 536.9 66.23 408.4 351.7 295.0 238.3 181.6 #N/A #N/A
67 531.5 59.63 510.3 467.6 410.9 354.2 297.5 240.8 184.1 67 506.9 65.58 492.7 457.3 400.6 343.9 287.2 230.5 173.8
62 526.0 59.61 526.0 524.8 500.5 443.8 387.1 330.4 273.7 62 504.8 65.74 504.8 504.0 479.7 423.0 366.3 309.6 252.9
57 525.7 59.60 525.7 524.5 500.2 443.5 386.8 330.1 273.4 57 504.6 65.74 504.6 503.7 479.4 422.7 366.0 309.3 252.6
20000
72 575.6 60.49 456.7 391.9 327.1 262.3 197.5 #N/A #N/A
20000
72 548.1 66.46 446.6 381.8 317.0 252.2 187.4 #N/A #N/A
67 542.8 59.86 542.8 505.8 441.0 376.2 311.4 246.6 181.8 67 517.5 65.81 517.5 495.2 430.4 365.6 300.8 236.0 171.2
62 537.2 59.84 537.2 537.2 537.2 472.4 407.6 342.8 278.0 62 515.3 65.98 515.3 515.3 515.3 450.5 385.7 320.9 256.1
57 537.0 59.83 537.0 537.0 537.0 472.2 407.4 342.6 277.8 57 515.1 65.97 515.1 515.1 515.1 450.3 385.5 320.7 255.9
22500
72 583.2 60.64 493.8 420.9 348.0 275.1 202.2 #N/A #N/A
22500
72 554.9 66.60 483.9 411.0 338.1 265.2 192.3 #N/A #N/A
67 549.9 60.00 549.9 531.5 469.2 396.3 323.4 250.5 177.6 67 523.9 65.95 523.9 512.8 459.0 386.1 313.2 240.3 167.4
62 544.3 59.98 544.3 544.3 544.3 471.4 398.5 325.6 252.7 62 521.8 66.12 521.8 521.8 521.8 448.9 376.0 303.1 230.2
57 544.0 59.97 544.0 544.0 544.0 471.1 398.2 325.3 252.4 57 521.5 66.11 521.5 521.5 521.5 448.6 375.7 302.8 229.9
25000
72 590.8 60.78 530.8 449.8 368.8 287.8 206.8 #N/A #N/A
25000
72 561.7 66.74 521.2 440.2 359.2 278.2 197.2 #N/A #N/A
67 557.1 60.14 557.1 557.1 497.3 416.3 335.3 254.3 173.3 67 530.4 66.09 530.4 530.4 487.7 406.7 325.7 244.7 163.7
62 551.4 60.12 551.4 551.4 551.4 470.4 389.4 308.4 227.4 62 528.2 66.26 528.2 528.2 528.2 447.2 366.2 285.2 204.2
57 551.1 60.11 551.1 551.1 551.1 470.1 389.1 308.1 227.1 57 527.9 66.25 527.9 527.9 527.9 446.9 365.9 284.9 203.9
TEMPERATURE OF AIR ON CONDENSER COIL 125ºF
15000
72 499.8 71.9 361.0 312.4 263.8 215.2 166.6 #N/A #N/A
1
These capacities are gross ratings. For net capacity, deduct air blower motor,
MBH - 3.415 X kW. Refer to the appropriate Blower Performance Table for the
kW of the supply air blower motor.
2
These ratings include condenser fan motors and the compressor motors but not
the supply blower motor.
67 472.6 71.3 458.0 409.4 360.8 312.2 263.6 215.0 166.4
62 473.8 71.6 473.8 472.8 424.2 375.6 327.0 278.4 229.8
57 473.6 71.6 473.6 472.6 424.0 375.4 326.8 278.2 229.6
17500
72 510.2 72.2 398.7 342.0 285.3 228.6 171.9 #N/A #N/A
67 482.4 71.5 475.1 447.0 390.3 333.6 276.9 220.2 163.5
62 483.6 71.9 483.6 483.1 458.8 402.1 345.4 288.7 232.0
57 483.4 71.9 483.4 482.9 458.6 401.9 345.2 288.5 231.8
20000
72 520.5 72.4 436.4 371.6 306.8 242.0 177.2 #N/A #N/A
67 492.2 71.8 492.2 484.5 419.7 354.9 290.1 225.3 160.5
62 493.5 72.1 493.5 493.5 493.5 428.7 363.9 299.1 234.3
57 493.2 72.1 493.2 493.2 493.2 428.4 363.6 298.8 234.0
22500
72 526.6 72.6 474.0 401.1 328.2 255.3 182.4 #N/A #N/A
67 497.9 71.9 497.9 494.1 448.9 376.0 303.1 230.2 157.3
62 499.2 72.3 499.2 499.2 499.2 426.3 353.4 280.5 207.6
57 499.0 72.2 499.0 499.0 499.0 426.1 353.2 280.3 207.4
25000
72 532.7 72.7 511.5 430.5 349.5 268.5 187.5 #N/A #N/A
67 503.7 72.0 503.7 503.7 478.1 397.1 316.1 235.1 154.1
62 505.0 72.4 505.0 505.0 505.0 424.0 343.0 262.0 181.0
57 504.8 72.4 504.8 504.8 504.8 423.8 342.8 261.8 180.8
