5407935-UUM-E-1020
28 Johnson Controls Ducted Systems
Part 2: Complete wireless setup
1. Select the network Wi-Fi.
2. Enter the password.
3. Enter the location name, for example, Home. The location name is a
name for the thermostat. See Figure 36.
4. Enter the room name, for example, Living room. The room name that
you choose is displayed in the room name pull-down menu of the
app Home screen. See Figure 37. Wireless setup is now complete.
NOTICE
You must connect the thermostat to the 2.4 GHz frequency on dual band
routers.
Figure 36: Wireless location
IMPORTANT: If the smart device fails to connect, on the thermostat
Wireless Status screen, tap the Wi-Fi icon, tap Disconnect, and
repeat step 1 to step 4.
A1416-001
