York Hx 3 S1-THXU280 User Manual

5407935-UUM-E-1020
Johnson Controls Ducted Systems 3
Figure 2 shows the tools required for installing the Hx 3 Touch Screen
Thermostat. It is best practice that a qualified technician performs the
installation.
Figure 2: Tools for Installation
ScrewdriverPencil Level
Wire Strippers Drill Hammer
7/32 in. Drill Bit (Plaster)
3/16 in. Drill Bit (Drywall)
A0976-002

York Hx 3 S1-THXU280 Specifications

General

Brand	York
Model	Hx 3 S1-THXU280
Category	Thermostat
Language	English
