York Predator DF 090 User Manual

246699-YTG-D-1208
Johnson Controls Unitary Products 11
TABLE 2: DF PHYSICAL DATA
Component
Models
078 090 102 120
Evaporator
Blower
Blower, Centrifugal (Dia. X Wd. in.) 15 x 15 12 x 12 12 x 12 15 x 15
Motor, Standard (HP) 1.5 2 3 2
Motor, Optional (HP) 2333
Evaporator
Coil
Rows 3334
Fins per Inch 15 15 15 15
Height (in.) 32323240
Face Area (ft.
2
)
10.67 10.67 10.67 13.2
Condenser
Fan
(2 per Unit)
Propeller Dia. (in.) 24 24 24 24
Motor (HP, each) 1/3 1/3 3/4 3/4
CFM, Nominal (each) 3400 3400 4400 4400
Condenser
Coil
(2 per unit)
Rows 1 1
Sys 1: 2 Row
2
Sys 2: 1 Row
Fins per Inch 20 20 20 20
Height (in.) 44363644
Face Area (ft.
2
)
14.5 12 12 14.5
Refrigerant
Charge
System 1 (lb/oz) 6/12 5/4 9/12 11/1
System 2 (lb/oz) 6/4 5/0 5/6 11/1
Compressors
Quantity 2222
Type Recip Recip Recip Recip
Air Filters
Size (Wd. x Ht. x Thickness in.) 25x20x2 25x16x2 25x16x2 25x20x2
Number Per Unit 4444
