246699-YTG-D-1208
Johnson Controls Unitary Products 35
FIGURE 8 - BOTTOM DUCT OPENINGS (FROM ABOVE)
32-11/16
6-13/16
6-13/16
27-1/2
18
21-3/16
19-3/16
17-3/16
14-23/32
16-3/8
18 1/16
12-5/16
6-13/16
24
21
LEFT
Bottom gas
supply entry
Bottom Power,
Control and
Convenience
Outlet Wiring
SUPPLY
AIR
RETURN
AIR
FRONT
FIGURE 9 - REAR DUCT DIMENSIONS
Dot Plugs
18-1/4
5-5/32
31-11/16
2-31/32
18-1/4
Return
Air
Supply
Air
A
B
C
REAR DUCT DIMENSIONS
CABINET SIZE
DIMENSION
“A” “B” “C”
50 3/4” 28 1/4 18 1/16 28 1/4
42” 27 3/4 12 1/16 27 1/2
