TABLE 8: COOLING CAPACITY DF120 (10 TON) UNIT
Return Air Outdoor Ambient Temperature 85°F Outdoor Ambient Temperature 95°F
CFM
WB
(°F)
Gross
Cap.
*
(MBH)
Input
†
Power
(kW)
Gross Sensible Capacity (MBH)
*
Return Air Dry Bulb (°F)
Gross
Cap.
*
(MBH)
Input
†
Power
(kW)
Gross Sensible Capacity (MBH)
*
Return Air Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
3000
72 119.5 8.47 73.6 65.1 56.5 48.0 39.4 - - 119.3 9.31 73.2 64.7 56.1 47.6 39.0 - -
67 116.6 8.49 94.8 86.2 77.7 69.1 60.5 52.0 43.4 114.0 9.25 94.3 85.7 77.2 68.6 60.1 51.5 43.0
62 112.6 8.43 112. 106. 98.3 89.8 81.2 72.7 64.1 109.4 9.11 109. 105. 97.0 88.4 79.9 71.3 62.8
57 109.2 8.41 109. 109. 101. 93.0 84.4 75.9 67.3 109.1 9.16 108. 100. 91.6 83.0 74.4 65.9 57.3
3500
72 122.4 8.52 80.0 69.9 59.8 49.7 39.6 - - 122.0 9.34 80.0 69.9 59.8 49.6 39.5 - -
67 119.4 8.54 102. 92.3 82.2 72.1 62.0 51.9 41.7 116.6 9.28 102. 92.3 82.2 72.1 61.9 51.8 41.7
62 115.3 8.47 115. 112. 104. 94.0 83.9 73.8 63.6 111.9 9.13 111.9 110. 103. 93.1 83.0 72.9 62.8
57 111.8 8.45 111.8 111.8 107. 97.3 87.2 77.1 67.0 111.6 9.19 111.4 107. 97.5 87.3 77.2 67.1 57.0
4000
72 125.2 8.56 86.4 74.8 63.1 51.4 39.8 - - 124.7 9.37 86.7 75.0 63.4 51.7 40.0 - -
67 122.1 8.59 110. 98.4 86.7 75.0 63.4 51.7 40.1 119.2 9.31 110. 98.8 87.1 75.5 63.8 52.1 40.5
62 118.0 8.52 118. 118. 109. 98.2 86.5 74.8 63.2 114.4 9.16 114. 114. 109. 97.8 86.2 74.5 62.8
57 114.4 8.50 114. 114. 113. 101. 90.0 78.4 66.7 114.1 9.22 114. 114. 103. 91.7 80.0 68.4 56.7
4500
72 125.5 8.56 91.5 78.2 64.9 51.6 38.3 - - 125.8 9.41 92.6 79.3 66.0 52.8 39.5 - -
67 122.4 8.59 115. 102. 89.2 75.9 62.6 49.3 36.1 120.2 9.35 115. 104. 90.8 77.5 64.2 50.9 37.7
62 118.3 8.52 118. 118. 113. 99.7 86.4 73.1 59.8 115.4 9.20 115. 115. 112. 99.7 86.4 73.1 59.8
57 114.7 8.50 114. 114. 114. 100. 87.6 74.3 61.0 115.1 9.25 115. 115. 107. 94.4 81.1 67.8 54.6
5000
72 125.8 8.56 96.5 81.6 66.7 51.8 36.9 - - 126.9 9.45 98.5 83.6 68.7 53.8 38.9 - -
67 122.7 8.59 121. 106. 91.7 76.8 61.9 47.0 32.1 121.3 9.38 121. 109. 94.5 79.6 64.6 49.7 34.8
62 118.5 8.52 118. 118. 116. 101. 86.3 71.4 56.5 116.4 9.24 116. 116. 116. 101. 86.6 71.7 56.8
57 115.0 8.50 115. 115. 115. 100. 85.2 70.3 55.3 116.0 9.29 116. 116. 112. 97.1 82.2 67.3 52.4
Outdoor Ambient Temperature 105°F Outdoor Ambient Temperature 115°F
3000
72 113.3 10.02 71.2 62.6 54.1 45.5 37.0 - - 107.2 10.74 69.1 60.5 52.0 43.4 34.9 - -
67 106.2 9.85 91.5 82.9 74.4 65.8 57.3 48.7 40.2 98.5 10.44 88.7 80.1 71.6 63.0 54.5 45.9 37.4
62 103.6 9.74 103. 97.2 88.7 80.1 71.6 63.0 54.4 97.8 10.37 97.4 88.9 80.3 71.8 63.2 54.7 46.1
57 103.3 9.75 102. 93.9 85.3 76.8 68.2 59.7 51.1 97.6 10.34 96.2 87.7 79.1 70.6 62.0 53.5 44.9
3500
72 117.0 10.10 78.6 68.5 58.4 48.2 38.1 - - 111.9 10.85 77.2 67.1 57.0 46.8 36.7 - -
67 109.7 9.92 100. 90.4 80.3 70.2 60.1 50.0 39.9 102.8 10.55 97.9 88.5 78.4 68.3 58.2 48.1 38.0
62 107.0 9.81 106. 103. 95.6 85.5 75.4 65.3 55.2 102.1 10.48 101. 97.7 88.0 77.9 67.8 57.7 47.6
57 106.7 9.82 106. 102. 92.1 82.0 71.9 61.8 51.6 101.9 10.45 101. 96.8 86.7 76.6 66.5 56.4 46.3
4000
72 120.7 10.17 86.0 74.3 62.6 51.0 39.3 - - 116.6 10.96 85.3 73.6 61.9 50.3 38.6 - -
67 113.2 9.99 108. 97.9 86.2 74.5 62.9 51.2 39.5 107.1 10.66 107. 96.9 85.3 73.6 61.9 50.3 38.6
62 110.4 9.87 110. 110. 102. 90.9 79.3 67.6 55.9 106.4 10.59 106. 106. 95.7 84.0 72.4 60.7 49.0
57 110.1 9.89 110. 110. 98.8 87.2 75.5 63.8 52.2 106.2 10.56 106. 105. 94.3 82.6 71.0 59.3 47.6
4500
72 121.9 10.22 92.5 79.2 65.9 52.6 39.3 - - 117.9 11.03 92.3 79.1 65.8 52.5 39.2 - -
67 114.3 10.04 112. 103. 90.7 77.4 64.1 50.8 37.5 108.3 10.73 108. 103. 90.6 77.3 64.0 50.7 37.4
62 111.5 9.93 111.5 111.5 107. 94.0 80.7 67.4 54.1 107.7 10.65 107. 107. 101. 88.4 75.1 61.8 48.5
57 111.2 9.94 111.2 111.2 103. 90.6 77.3 64.1 50.8 107.4 10.62 107. 107. 100. 86.9 73.6 60.3 47.0
5000
72 123.1 10.27 99.0 84.1 69.2 54.3 39.3 - - 119.3 11.10 99.4 84.5 69.6 54.7 39.8 - -
67 115.4 10.09 115. 109. 95.2 80.3 65.3 50.4 35.5 109.6 10.79 109. 109. 95.9 81.0 66.1 51.1 36.2
62 112.6 9.98 112. 112. 112. 97.1 82.2 67.3 52.4 108.9 10.72 108. 108. 107. 92.7 77.8 62.9 48.0
57 112.3 9.99 112. 112. 109. 94.1 79.2 64.3 49.4 108.6 10.68 108. 108. 106. 91.1 76.2 61.3 46.4
Outdoor Ambient Temperature 125°F
3000
72 101.1 11.4 67.0 58.5 49.9 41.3 32.8 - -
67 90.7 11.0 85.9 77.3 68.8 60.2 51.7 43.1 34.6
62 92.0 11.0 91.4 80.5 72.0 63.4 54.9 46.3 37.8
57 91.8 10.9 90.0 81.5 72.9 64.4 55.8 47.3 38.7
3500
72 106.8 11.6 75.8 65.7 55.6 45.4 35.3 - -
67 95.9 11.2 95.7 86.7 76.6 66.4 56.3 46.2 36.1
62 97.2 11.2 96.9 91.5 80.4 70.3 60.2 50.1 40.0
57 97.0 11.1 96.1 91.7 81.3 71.2 61.1 51.0 40.9
4000
72 112.6 11.8 84.5 72.9 61.2 49.5 37.9 - -
67 101.1 11.3 101. 96.0 84.3 72.7 61.0 49.4 37.7
62 102.5 11.3 102. 102. 88.8 77.1 65.5 53.8 42.1
57 102.2 11.2 102. 101. 89.7 78.1 66.4 54.8 43.1
4500
72 114.0 11.8 92.2 78.9 65.6 52.4 39.1 - -
67 102.4 11.4 102. 102. 90.5 77.2 63.9 50.6 37.3
62 103.8 11.4 103. 103. 96.0 82.7 69.4 56.1 42.9
57 103.5 11.3 103. 103. 96.4 83.1 69.8 56.5 43.2
5000
72 115.4 11.9 99.9 85.0 70.1 55.2 40.3 - -
67 103.7 11.5 103. 103. 96.6 81.7 66.8 51.8 36.9
62 105.1 11.5 105. 105. 103. 88.3 73.4 58.5 43.6
57 104.8 11.4 104. 104. 103. 88.1 73.2 58.2 43.3
* The capacities are gross ratings. For net capacity,
deduct indoor blower motor, MBH=3.415 x kW.
Refer to the appropriate Blower Performance table
for the kW of the supply air blower motor.
†
Input power includes the condenser and compressor
motors but not the indoor blower motor.
