246699-YTG-D-1208
Johnson Controls Unitary Products 39
FIGURE 15 - SLAB ECONOMIZER END RETURN W/POWER EXHAUST
2EE04705X24
Slab Economizer
1EH0409
Barometric Relief Hood
1EH0409
Barometric Relief Damper
1EH0409
Fresh Air Hood
2PE047032XX
Power Exhaust
Field Installed
Duct Work
