York PREDATOR MagnaDRY DR090 User Manual

127878-YIM-C-1208
Johnson Controls Unitary Products 21
FIGURE 24 - FIELD WIRING DISCONNECT - COOLING UNIT WITH/WITHOUT ELECTRIC HEAT
FIGURE 25 - FIELD WIRING DISCONNECT-COOLING UNIT WITH GAS HEAT
TERMINAL BLOCK TB1
FACTORY OR FIELD
SUPPLIED DISCONNECT
GROUND
LUG
THREE
PHASE
POWER
SUPPLY
L1
T1
L2
T2
T3
L3
FACTORY OR FIELD
SUPPLIED DISCONNECT
THREE
PHASE
POWER
SUPPLY
GROUND
LUG
CONTACTOR 1M
