York Predator ZF078 User Manual

5167798-YTG-J-0218
16 Johnson Controls Unitary Products
Circuitry Type Intertwined Intertwined Intertwined Intertwined Intertwined
Refrigerant control TXV TXV TXV TXV TXV
CONDENSER FAN DATA
Quantity of Fans 2 2 2 2 4
Fan diameter (Inch) 24 24 24 24 24
Type Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct
Quantity of motors 2 2 2 2 4
Motor HP each 1/3 1/3 3/4 3/4 3/4
No. speeds 1 1 1 1 1
RPM 850 850 1110 1110 1110
Total CFM 6200 7600 9500 9500 11200
BELT DRIVE EVAP FAN DATA
Quantity 1 1 1 1 1
Fan Size (Inch) 12 x 12 12 x 12 15 x 15 15 x 15 15 x 15
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Motor Sheave 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VP56
Blower Sheave AK74 AK64 AK74 AK61 AK89 AK74 AK84 AK74 AK74 BK77
Belt A49 A49 A49 A49 A56 A54 A56 A54 A54 BX55
Motor HP each 1-1/2 2 1-1/2 3 2 3 2 3 3 5
RPM 1725 1725 1725 1725 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56 56 56 56 184T
FILTERS
Quantity - Size
4 - (24 x 16 x 2)
5
,
6
4 - (24 x 16 x 2)
4, 5
4 - (24 x 20 x 2)
4, 5
4 - (24 x 20 x 2)
4, 5
4 - (24 x 20 x 2)
4, 5
4 - (24 x 16 x 4)
7
4 - (24 x 16 x 4)
6
4 - (24 x 20 x 4)
6
4 - (24 x 20 x 4)
6
4 - (24 x 20 x 4)
6
1. Cooling Only Unit or Cooling Unit with Electric Heat
2. Cooling Unit with Gas Heat
3. 1ST Stage 60% of 2nd Stage
4. ZF090 and ZF150 have crankcase heaters standard
5. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value) 3
6. 2 In. Pleated, Optional, MERV 8
7. 4 In. Pleated, Optional, MERV 13
ZF078-150 Physical Data (Continued)
Component
Models
ZF078 ZF090 ZF102 ZF120 ZF150
Nominal Tonnage 6.5 7.5 8.5 10 12.5
