5167798-YTG-J-0218
18 Johnson Controls Unitary Products
Capacity Performance
ZF078-150 Cooling Capacities
ZF078 (6.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1625
77 102.9 5.0 41.5 34.0 26.6 - - - 96.2 5.6 39.9 32.5 25.0 - - -
72 94.8 5.0 53.8 46.4 38.9 31.5 - - 88.3 5.5 51.6 44.2 36.7 29.3 - -
67 86.7 5.0 66.1 58.7 51.3 43.8 36.4 - 80.3 5.5 63.3 55.8 48.4 41.0 33.6 -
62 79.2 5.0 79.2 72.4 61.4 54.0 46.6 39.1 72.8 5.4 72.8 69.4 58.6 51.1 43.7 36.3
1950
77 106.6 5.0 46.7 38.0 29.3 - - - 99.6 5.6 44.9 36.2 27.6 - - -
72 98.2 5.0 60.3 51.5 42.8 34.1 - - 91.4 5.5 57.8 49.1 40.4 31.7 - -
67 89.8 5.0 73.8 65.1 56.3 47.6 38.9 - 83.1 5.5 70.6 61.9 53.3 44.6 35.9 -
62 82.0 5.0 82.0 77.5 67.5 58.8 50.0 41.3 75.4 5.4 75.4 73.1 64.4 55.8 47.1 38.4
57 79.2 4.9 79.2 79.2 71.1 62.4 53.6 44.9 74.4 5.4 74.4 74.4 66.4 57.7 49.1 40.4
2275
77 110.2 5.0 52.0 41.9 31.9 - - - 103.0 5.6 49.9 40.0 30.1 - - -
72 101.6 5.0 66.7 56.7 46.7 36.6 - - 94.4 5.5 63.9 54.0 44.1 34.2 - -
67 92.9 5.0 81.5 71.4 61.4 51.4 41.3 - 85.9 5.5 78.0 68.1 58.1 48.2 38.3 -
62 84.8 5.0 84.8 82.5 73.6 63.6 53.5 43.5 77.9 5.4 77.9 76.8 70.3 60.4 50.5 40.6
57 81.9 4.9 81.9 81.9 77.5 67.5 57.4 47.4 76.9 5.4 76.9 76.9 72.5 62.5 52.6 42.7
2600
77 113.9 5.0 57.2 45.9 34.5 - - - 106.3 5.6 54.9 43.7 32.6 - - -
72 104.9 5.0 73.2 61.9 50.5 39.2 - - 97.5 5.5 70.1 58.9 47.8 36.6 - -
67 95.9 5.0 89.2 77.8 66.5 55.2 43.8 - 88.7 5.5 85.3 74.2 63.0 51.8 40.7 -
62 87.6 5.0 87.6 87.6 79.7 68.3 57.0 45.7 80.4 5.5 80.4 80.4 76.2 65.0 53.8 42.7
57 84.6 4.9 84.6 84.6 83.9 72.6 61.2 49.9 79.4 5.4 79.4 79.4 78.5 67.3 56.2 45.0
2925
72 107.2 5.0 78.2 65.9 53.6 41.4 - - 99.5 5.6 75.3 63.1 51.0 38.8 - -
67 98.0 5.0 94.6 82.9 70.6 58.4 46.1 - 90.5 5.5 88.8 79.3 67.2 55.0 42.9 -
62 89.5 5.0 89.5 89.5 85.5 73.3 61.0 48.7 82.0 5.5 82.0 82.0 79.9 67.8 55.6 43.5
57 86.5 4.9 86.5 86.5 86.1 73.8 61.6 49.3 81.0 5.4 81.0 81.0 80.5 68.4 56.2 44.1
3250
72 109.4 5.0 83.1 70.0 56.8 43.6 - - 101.4 5.6 80.4 67.3 54.2 41.0 - -
67 100.1 5.0 100.1 87.9 74.7 61.6 48.4 - 92.3 5.5 92.3 84.5 71.4 58.3 45.1 -
62 91.4 5.0 91.4 91.4 91.4 78.2 65.0 51.8 83.6 5.5 83.6 83.6 83.6 70.5 57.4 44.2
57 88.3 4.9 88.3 88.3 88.3 75.1 61.9 48.7 82.5 5.4 82.5 82.5 82.5 69.4 56.3 43.1
95°F 105°F
1625
77 89.6 6.1 38.3 30.9 23.5 - - - 82.4 6.7 33.7 28.5 21.2 - - -
72 81.7 6.1 49.3 41.9 34.5 27.1 - - 74.8 6.6 46.6 39.3 31.9 24.6 - -
67 73.9 6.0 60.4 53.0 45.6 38.2 30.8 - 67.2 6.5 59.4 50.0 42.7 35.4 28.1 -
62 66.5 5.9 66.5 66.5 55.7 48.3 40.9 33.5 61.3 6.4 61.3 61.3 51.7 44.4 37.1 29.8
1950
77 92.6 6.1 43.0 34.4 25.8 - - - 85.1 6.7 40.4 31.9 23.4 - - -
72 84.5 6.1 55.2 46.6 38.0 29.4 - - 77.3 6.6 52.3 43.8 35.3 26.8 - -
67 76.5 6.0 67.4 58.8 50.2 41.6 33.0 - 69.4 6.5 64.2 55.7 47.2 38.7 30.2 -
62 68.7 5.9 68.7 68.7 61.4 52.8 44.2 35.6 63.3 6.4 63.3 63.3 57.2 48.6 40.1 31.6
57 69.5 5.9 69.5 69.5 61.7 53.1 44.5 35.9 61.4 6.4 61.4 61.4 53.9 45.4 36.9 28.4
2275
77 95.7 6.2 47.8 38.0 28.2 - - - 87.8 6.8 47.1 35.3 25.6 - - -
72 87.3 6.1 61.1 51.3 41.5 31.8 - - 79.7 6.7 58.1 48.4 38.7 29.0 - -
67 79.0 6.0 74.4 64.7 54.9 45.1 35.3 - 71.7 6.5 69.0 61.4 51.7 42.0 32.3 -
62 71.0 5.9 71.0 71.0 67.0 57.2 47.4 37.6 65.3 6.4 65.3 65.3 62.6 52.9 43.2 33.5
57 71.8 6.0 71.8 71.8 67.4 57.6 47.8 38.0 63.3 6.4 63.3 63.3 59.0 49.3 39.6 29.9
2600
77 98.7 6.2 52.6 41.6 30.6 - - - 90.5 6.8 53.7 38.7 27.8 - - -
72 90.1 6.1 67.0 56.0 45.1 34.1 - - 82.2 6.7 63.8 52.9 42.0 31.1 - -
67 81.5 6.0 81.5 70.5 59.5 48.5 37.5 - 73.9 6.6 73.9 67.1 56.2 45.3 34.4 -
62 73.3 6.0 73.3 73.3 72.7 61.7 50.7 39.7 67.3 6.5 67.3 67.3 68.0 57.2 46.3 35.4
57 74.1 6.0 74.1 74.1 73.1 62.1 51.1 40.1 65.3 6.4 65.3 65.3 64.1 53.2 42.4 31.5
2925
72 91.7 6.1 72.4 60.3 48.3 36.3 - - 83.6 6.7 69.1 57.1 45.1 33.2 - -
67 83.0 6.0 83.0 75.8 63.8 51.7 39.7 - 75.2 6.6 75.1 70.9 60.4 48.4 36.5 -
62 74.6 6.0 74.6 74.6 74.3 62.2 50.2 38.2 68.5 6.5 68.5 68.5 68.9 56.9 44.9 33.0
57 75.5 6.0 75.5 75.5 74.9 62.9 50.9 38.8 66.4 6.4 66.4 66.4 65.9 53.9 41.9 30.0
3250
72 93.4 6.1 77.7 64.6 51.5 38.4 - - 85.1 6.7 74.3 61.3 48.3 35.2 - -
67 84.4 6.0 84.4 81.1 68.1 55.0 41.9 - 76.4 6.6 76.4 74.8 64.6 51.5 38.5 -
62 75.9 6.0 75.9 75.9 75.9 62.8 49.7 36.6 69.7 6.5 69.7 69.7 69.7 56.6 43.6 30.5
57 76.8 6.0 76.8 76.8 76.8 63.7 50.6 37.5 67.6 6.4 67.6 67.6 67.6 54.5 41.5 28.5
