York Predator ZF078 User Manual

5167798-YTG-J-0218
Johnson Controls Unitary Products 63
ZF150
LEFT
59.00
A
C
D
E
F
4.19
27.31
89.00
21.19
FRONT
SEE DETAIL B
FOR DRAIN LOCATION
11.38
SEE DETAIL A FOR GAS INLET
B
29.95 30.11
14.92
58.09
14.92
14.92
45.64
4X Ø 24.38
ZF078-150 Unit Physical Dimensions
Unit Model Number
Dimension (in.)
ABCDEF
078 42 89 22 1/8 18 3/16 15 3/16 6 3/16
090 42 89 22 1/8 18 3/16 15 3/16 6 3/16
102 50 3/4 89 30 3/16 24 3/16 17 3/16 6 3/16
120 50 3/4 89 30 3/16 24 3/16 17 3/16 6 3/16
150 50 3/4 119 1/2 30 3/16 24 3/16 17 3/16 6 3/16

York Predator ZF078 Specifications

General

Brand	York
Model	Predator ZF078
Category	Air Conditioner
Language	English
