York YST User Manual

JOHNSON CONTROLS
158
FORM 160.67-O1
ISSUE DATE: 4/1/2015
SECTION 3 - PRINTERS
FIGURE 57 - SAMPLE PRINTOUT (SALES ORDER)
YORK SaleS ORdeR
ChilleR id 3
(c) 1997 - 2004 YORK INTERNATIONAL CORPORATION
Tue 20 Apr 2004 4:51:41 PM
Order Information
------------------------------------------------------
Commissioning Date = 28 Jul 2004
Job Name = UConn Co-Gen
Job Location = Storrs, CT
Model Number = YSTWFYDJ4-KD7
York Order Number = 03-105495-01
Panel Serial Number = JLR-071
Chiller Serial Number = GANM 285180
Design Load - Evaporator
-------------------------------------------------------
Passes = 2
Design Working Pressure = 150
Fouling Factor = .0001
Pressure Drop = 18.5
Nozzle Arrangement In = B
Nozzle Arrangement Out = C
Leaving Temperature = 42.0
Return Temperature = 54.0
GPM = 4200
Tubes = 182
Design Load - Condenser
------------------------------------------------------
Passes = 2
Design Working Pressure = 150
Fouling Factor = .00025
Pressure Drop = 23.8
Nozzle Arrangement In = 12
Nozzle Arrangement Out = 13
Leaving Temperature = 94.34
Return Temperature = 85.0
GPM = 6300
Tubes = 261
Design Load - Steam Condenser
-------------------------------------------------------
Passes = 1
Design Working Pressure = 150
Fouling Factor = 85
Pressure Drop = 12.2
Nozzle Arrangement In = Bottom
Nozzle Arrangement Out = top
Leaving Temperature = 100.16
Return Temperature = 94.34
GPM = 6300
Tubes = 0.049
Turbine Information
--------------------------------------------------------
horsepower = 1613
steam pressure = 125
steam temperature = 353
# NozzLES = 13
Expansion Ratio = 1.1
# OL Nozzles = 1
Exhaust Pressure = 2.8
System Information
-------------------------------------------------------
Refrigerant = R134a
Tons = 2100
Gear Code = PS
Liquid Type = Water
Brine Percent = 0
Power [volts/ph/hz] = 460/3/60

York YST Specifications

General

Brand	York
Model	YST
Category	Chiller
Language	English
