Z-CAM E2 User Manual

 USB: USB 3.0 Type C port for camera control and data transformation only.
 Remote: 2.5mm jack socket, compatible with Sony LANC protocol.
 XLR audio-in: 5-pin LEMO port for dual-channel XLR microphone, require additional
XLR audio connector (compatible with ARRI Mini XLR connector).
 COM: DB-9 connector with RS232 protocol supported.
 I/O: 10-pin LEMO port for multi-camera synchronization (with exclusive Z CAM E2
Sync Cable, not included).
 Camera Mode Switch: The switch to set working mode of camera, of which M
(Master) and S (Slave) is for multi-camera synchronization (with exclusive Z CAM E2
Sync Cable, not included), and I for individual mode (default).
1.6. Power Options
 External Power Source: The camera comes with a LEMO power cable (D-TAP plug
end), D-TAP/DC connector and AC/DC power adapter, which can use AC 100~240V
power source.
 Camera Battery: The battery socket is compatible with SONY NP-F series batteries,
including NP-F970/770/550 etc. (Note 2)

Z-CAM E2 Specifications

General

HDMI	Yes
PictBridge	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Optical zoom	- x
Image stabilizer	-
Sensor type	CMOS
Total megapixels	- MP
Optical sensor size	4/3 \
Effective megapixels (movie)	10.28 MP
Video resolutions	3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	160 fps
Video formats supported	H.264, H.265
Maximum video resolution	4096 x 2160 pixels
Bitrate at maximum video resolution	300 Mbit/s
Camcorder media type	Memory card
Compatible memory cards	CFast 2.0
Internal storage capacity	- GB
ISO sensitivity	500, 640, 800, 1000, 1250, 1600, 2000, 2200, 2250, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12500, 12800, 16000, 20000, 25000, 25600, 32000, 40000, 50000, 51200, 80000, 102400
Light exposure modes	Auto, Manual
Camcorder type	Handheld camcorder
Wi-Fi standards	Wi-Fi 4 (802.11n)
Ethernet interface type	Gigabit Ethernet
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Display diagonal	- \
Product color	Black
Housing material	Aluminum
Maximum image resolution	- pixels
Audio system	stereo
PCM digital audio	24-bit/48 kHz
Audio formats supported	AAC, PCM
Charging source	Battery, DC
Battery capacity	- mAh
Battery life (max)	- h

Weight and Dimensions

Depth	89.1 mm
Width	91.2 mm
Height	99.2 mm
Weight	757 g
