Technical Specifications
161
Memory 2 GB RAM/16 GB or 32 GB Flash
Output Power USB - 5 VDC @ 500 mA max
User Environment
Operating Temperature -10°C to 50°C (14°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Relative Humidity Operating: 5 to 95% non-condensing
Drop Specification Multiple 1.2 m (4 ft.) to tile over concrete per MIL-STD at room
temperature.
Tumble 300 0.5 m (1.6 ft.) tumbles
Sealing IP54
Electrostatic Discharge (ESD) ± 20 kVDC air discharge, ± 10 kVDC direct discharge, ± 10 kVDC indirect
discharge
Vibration 4 g’s peak, 5 Hz to 2 kHz, 1 hour duration per axis
Thermal Shock -40°C to 70°C (-40°F to 158°F) rapid transition. 10 cycles: (1 cycle = 1.25
hours at -40°C and 1.25 hours at 70°C.
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer
Light Sensor Ambient light sensor to auto adjust display backlight brightness
Proximity Sensor Automatically detects when the user places the handset against head
during a phone call to disable display output and touch input.
Wireless LAN Data and Voice Communications
Radio IEEE 802.11 a/b/g/n/ac/d/r/k/w/v/h/i IPv4, IPv6
Data Rates Supported 2.4GHz: 802.11b/g/n - up to 150 Mbps
5GHz: 802.11a/n/ac - up to 433.3 Mbps
Operating Channels 2.4 GHz: Chan 1 - 13; 1 - 11 (US)
5GHz: Chan 36-48, 52-64, 100-140, 149-151, 161-165
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/frequencies and bandwidth depend on
regulatory rules and certification agency.
Security and Encryption WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES); WPA/WPA2
Enterprise (TKIP and AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2),
EAP-TLS, PEAPv0-MSCHAPv2.
Certifications 802.11 a/b/g/n/ac; WPA; WPA2
Fast Roam 802.11
Wireless PAN Data and Voice Communications
Bluetooth Bluetooth v4.2 Low Energy (LE)
Data Capture Specifications
Table 11 TC20 Technical Specifications (Continued)
Item Description
