H3140 Maintenance Management Guide
Figure 2-1 The Front Panel
Figure 2-2 The indicators
Indicator Status Description
Fixed green All services are available. At lease one wireless radio is
enabled.
Fixed red One or more subscription services are currently unavail-
able.
Green flashing Operator is configuring the modem remotely.
Fixed orange Bootloader in progress.
Flashing orange The device is upgraded remotely or locally.
Power
Off The device is powered off.
Fixed green Connected to the WAN device.Linea (LAN4/
SFP)
Off Not connected to the WAN device.
6 SJ-20210621164956-009 | 2021-12-07(R1.0)
