4 Configure the Internet
Figure 4-15 Service Control-IPv4 Page
3. Configure the service control-IPv4 parameters.
Table 4-10 lists the local service control-IPv4 parameters.
Table 4-10 Parameter Descriptions for the Service Control-IPv4
Parameter Description
On/Off Click On to enable the function.
Click Off to disable the function.
Name Name of the service control item.The name must be specified.
Target Specify to discard or permit the data packages.
Ingress Specify the data stream inbound direction, and this parameter
must be specified.
If the Ingress is WAN_All, all the WAN connection can access
H3140.
If the Ingress is LAN, the LAN side can access H3140.
If the Ingress is a WAN or Route_3G connection, the connec-
tion selected can access H3140.
IP Range The IP address segment that needs to be filtered.
When the IP segment is null, it refers to all the IP addresses.
Service Type Specify the service that is permitted or denied to access.
4. Click Apply button to apply the changes.
Configure the Service Control-IPv6
5. Click Service Control-IPv6 to open Service Control-IPv6 page, see Figure 4-16.
SJ-20210621164956-009 | 2021-12-07(R1.0) 31
