4 Configure the Internet
If you have local servers for different services and you want to make them publicly ac-
cessible, you need to specify the port forwarding policy. With NAT applied, it translates
the internal IP addresses of these servers to a single IP address that is unique on the In-
ternet.
To the Internet users, all virtual servers on your LAN have the same IP Address. This IP
Address is allocated by your ISP. This address should be static, rather than dynamic, to
make it easier for Internet users to connect to your servers. However, you can use dy-
namic DNS feature to allow users to connect to your virtual servers by using a URL, in-
stead of an IP address.
Steps
1. On the main page of the H3140, select Internet > Security > Port Forwarding to
the Port Forwarding page,and then click the Create New Item, the page see Figure
4-20.
Figure 4-20 Port Forwarding Configuration Page
2. Configure the Port Forwarding parameters.
Table 4-14 lists the Port Forwarding settings parameters.
Table 4-14 Parameter Descriptions for the Port Forwarding
Parameter Description
On/Off Set radiobox On to enable the port forwarding function.
Name Virtual host name, which cannot be null.
Protocol Protocol name, including TCP, UDP, TCP AND UDP.
The default protocol is TCP.
SJ-20210621164956-009 | 2021-12-07(R1.0) 35
