Chapter4ServiceConguration
TheZXR102900EseriesswitchessupportfourPVLANsessions.EachPVLANsession
supportsanunlimitednumberofpromiscuousports.EachPVLANsupportsanunlimited
numberofisolatedorcommunityports.
ConguringPVLAN
ThePVLANcongurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#setvlanpvlansession<1-4>{promise-port<portlist>|promise-tr
unk<trunklist>}{isolate-port<portlist>|isolate-trunk<trunklist>}{commu
ni-port<portlist>|communi-trunk<trunklist>}
SetsthePVLANfunction.
clearvlanpvlan[session<1-4>]ClearsthePVLANconguration.
showvlanpvlan[session<1-4>](allcongurationmodes)DisplaysPVLANconguration.
zte(cfg)#setvlanpvlansession<1-4>{promise-port<portlist>|promise-
trunk<trunklist>|isolate-port<portlist>|isolate-trunk<trunklist>|commu
ni-port<portlist>|communi-trunk<trunklist>}
ConguringakindofPVLANport.
PVLANCongurationExampleOne
lCongurationDescription
AsshowninFigure4-15,addpromiscuousport26andisolatedports1,2,and3to
session1.
Figure4-15PVLANCONFIGURATIONEXAMPLE1
lCongurationProcedure
zte(cfg)#setvlanpvlansession1promis-port26isolate-port1-3
lCongurationVerication
zte(cfg)#showvlanpvlan
pvlansession:1
promis-ports:26
promis-trunks:
isolate-ports:1-3
isolate-trunks:
4-57
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2952E Specifications

General

Model	ZXR10 2952E
Category	Switch
Jumbo Frame	9K
Weight	4.5 kg
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 mm x 44 mm x 300 mm
Power Supply	AC 100-240V, 50/60Hz
VLAN	4K VLAN
Operating Temperature	0°C to 45°C
