Zte ZXR10 2952E User Manual

ZXR102900ESeriesCongurationGuide
1128.1200000ForwardDesignatedSSTPNone
2128.2200000ForwardDesignatedSSTPNone
2.ChecktheSTPstateofswitch2inthesystemview.
zte(cfg)#showstpinstance
Spanningtreeenabledprotocolstp
RootID:
Priority:32768Address:00.d0.d0.02.00.54
HelloTime(s):2MaxAge(s):20
ForwardDelay(s):15
RegRootID:
Priority:32768Address:00.d0.d0.29.52.06
RemainHops:20
BridgeID:
Priority:32768Address:00.d0.d0.29.52.06
HelloTime(s):2MaxAge(s):20
ForwardDelay(s):15MaxHops:20
InterfacePortIdCostStatusRoleBoundGuardStatus
-------------------------------------------------------
1128.1200000ForwardRootSSTPNone
2128.2200000DiscardAlternateSSTPNone
RSTPCongurationInstance
lCongurationDescription
AsshowninFigure4-11,conguretheRSTPfunctionofswitch1andswitch2,take
switch1astherootbridgeandblockaredundantportintheloop.Itrealizesloop
protectionandlinkbackupbetweenswitches.
Figure4-11RSTPCongurationInstance
lCongurationProcedure
zte(cfg)#setstpenable
/*enableSTPprotocolofswitch1andswitch2*/
zte(cfg)#setstpforceversionrstp
/*setforceversionofstpasrstp*/
lCongurationVerication
1.ChecktheSTPstateofswitch1inthesystemview.
zte(cfg)#showstpinstance
Spanningtreeenabledprotocolrstp
RootID:
Priority:32768Address:00.d0.d0.02.00.54
HelloTime(s):2MaxAge(s):20
4-38
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2952E Specifications

General

Model	ZXR10 2952E
Category	Switch
Jumbo Frame	9K
Weight	4.5 kg
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 mm x 44 mm x 300 mm
Power Supply	AC 100-240V, 50/60Hz
VLAN	4K VLAN
Operating Temperature	0°C to 45°C
