Chapter4ServiceConguration
Note:
1.TheintersectingnodeoftheprimaryringandtheSmartLinknodemustsetas
Edge-MasterorEdge-Transit.
2.TheportconnectingtheprimaryportandSmartLinkmustsetasAccess-Port.
3.TheSmartLinkcanbeusedwiththehierarchicalringatthesametime.
Cross-DeviceTCNSendingExample
lCongurationDescription
AsshowninFigure4-44,congureZESSontheZTEdevicesfromSW-1orSW-6.
Thedevicesareconnectedtodevicesofanothervender.ItisrequiredtoenableSTP .
Whenthelinkischangedover,SW-1isresponsibleforsendingTCNtoinformthe
uplinkdevicestocleartheMACentities.
4-109
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2952E Specifications

General

Model	ZXR10 2952E
Category	Switch
Jumbo Frame	9K
Weight	4.5 kg
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 mm x 44 mm x 300 mm
Power Supply	AC 100-240V, 50/60Hz
VLAN	4K VLAN
Operating Temperature	0°C to 45°C
