Current Consumption and Power Dissipation Appendix B Power Consumption
202 3BSE 027 941 R301
Current Consumption and Power Dissipation
Current Consumption and Power Dissipation
See Table 64 on page 202 for typical current consumption and power dissipation
data for AC 800M units.
(1) These figures apply only to the PM8xx. For current-consumption data relating to the CEXbus and the
ModuleBus units, see Table 65 on page 203.
The CPU supplies current, via TP830, to units on the CEX-bus and ModuleBus,
see Table 65 on page 203.
Table 64. Current Consumption and Power Dissipation Data for AC 800M Units
Unit
Current at 24 V Power Dissipation
Remarks
Typical Max Typical Max
PM856 180 mA 300 mA 5.0 W 8.0 W (1)
PM860 180 mA 300 mA 5.0 W 8.0 W (1)
PM861 250 mA 430 mA 6.0 W 10.3 W (1)
PM864 287 mA 487 mA 6.9 W 11.4 W (1)
CI851 150 mA 200 mA 3.6 W 5.0 W
CI852 140 mA 200 mA 3.4 W 5.0 W
CI853 100 mA 150 mA 2.4 W 3.6 W
CI854 190 mA 240 mA 4.6 W 5.8 W
CI855 150 mA 200 mA 3.6 W 5.0 W
CI856 120 mA 200 mA 2.9 W 5.0 W
CI857 150 mA 200 mA 3.6 W 5.0 W
