TypeLEDDisplay
See Faults (page 65).
continuous red
Faults of this type require stopping and restarting
the drive before it continues to function normally.
See Faults (page 65).
blinking red
A fault has occurred in another drive in the panel
bus.
continuous red
See Warnings (page 65).
blinking green
The connection between the control panel and the
drive is faulty.
continuous green
Check that the connection cable is properly at-
tached.
The control panel type is not compatible with the
drive you attempt to use it with.
continuous green
See Applicability (page 10).
The connection between the control panel and the
drive has been lost.
continuous green
Check the control panel network connections.
Select another drive.
64 Fault tracing
