ACH550-UH User’s Manual 1-319
Technical data
Air flow, 380…480 volt drives
The following table lists heat loss and air flow data for 380…480 volt drives.
-046A-2 R3 420 1434 134 79
-059A-2 R3 536
1829 134 79
-075A-2 R4 671
2290 280 165
-088A-2 R4 786
2685 280 165
-114A-2 R4 1014 3463 280 165
-143A-2 R6 1268
4431 405 238
-178A-2 R6 1575 5379 405 238
-221A-2 R6 1952 6666 405 238
-248A-2 R6 2189
7474 405 238
Drive Heat Loss Air Flow
ACH550-xx- Frame Size W BTU/Hr m
3
/h ft
3
/min
-03A3-4 R1 40 137 44 26
-04A1-4 R1 52 177 44 26
-06A9-4 R1 97
331 44 26
-08A8-4 R1 127 433 44 26
-012A-4 R1 172 587 44 26
-015A-4 R2 232
792 88 52
-023A-4 R2 337 1150 88 52
-031A-4 R3 457 1560 134 79
-038A-4 R3 562
1918 134 79
-045A-4 R3 667 2276 134 79
-044A-4 R4 667 2276 280 165
-059A-4 R4 907
3096 280 165
-072A-4 R4 1120
3820 280 165
-078A-4 R4 1295 4420 280 165
-097A-4 R4 1440
4915 280 165
-077A-4 R5 1295 4420 168 99
-096A-4 R5 1440
4915 168 99
-125A-4 R5 1940
6621 168 99
-124A-4 R6 1940 6621 405 238
-157A-4 R6 2310
7884 405 238
-180A-4 R6 2810
9590 405 238
-246A-4 R6 3850
13000 405 238
-245A-4 R7 3850 13000 300 540
-316A-4 R8 5300
18000 700 1220
Drive Heat Loss Air Flow
ACH550-xx- Frame Size W
BTU/Hr m
3
/h ft
3
/min
