Embedded fieldbus
Control interface
In general, the basic control interface between the fieldbus system and the drive
consists of:
Note: The words “output” and “input” are used as seen from the fieldbus controller
point of view. For example an output describes data flow from the fieldbus controller
to the bypass.
Planning
Network planning should address the following questions:
• What types and quantities of devices must be connected to the network?
• What control information must be sent to the system (drive only or system)?
• What feedback information must be sent from the bypass system to the
controlling system?
Protocol Control Interface Reference for more information
Modbus • Output Words
– Control word
– Reference1
– Reference2
• Input Words
–Status word
– Actual value 1
– Actual value 2
– Actual value 3
– Actual value 4
– Actual value 5
– Actual value 6
– Actual value 7
– Actual value 8
The content of these words is defined by profiles. For
details on the profiles used, see BACnet analog value
object instance summary – bypass on page 2-173
N2 • Binary output objects
• Analog output objects
• Binary input objects
• Analog input objects
N2 protocol technical data – system on page 2-109
and Bypass overview on page 2-118
FLN • Binary output points
• Analog output points
• Binary input points
• Analog input points
FLN protocol technical data – system on page 2-124
and Bypass overview on page 2-139
BACnet • Device management
• Binary output objects
• Analog output objects
• Binary input objects
• Analog input objects
BACnet protocol technical data – system on
page 2-148
