2-240 ACH550 E-Clipse Bypass User’s Manual
Technical data
1. “xxR” represents VCR, VDR, BCR and BDR.
2. UL Type/NEMA 3R enclosed units are provided with Bussman Type JJS or equivalent fuses. Fuse
ratings shown relate to latest production. Where installed product includes fuses of a lower rating,
either rating may be used.
380…480 volt fuses
3 ACH550-xxR-012A-2 R1 15 KTK-R-15
5 ACH550-xxR-017A-2 R1 30 KTK-R-30
7.5 ACH550-xxR-024A-2 R2 30 KTK-R-30
10 ACH550-xxR-031A-2 R2 60 JJS-60
15 ACH550-xxR-046A-2 R3 100 JJS-100
20 ACH550-xxR-059A-2 R3 100 JJS-100
25 ACH550-xxR-075A-2 R4 100 JJS-100
30 ACH550-xxR-088A-2 R4 200
170M1370
2
or
170M2617
40 ACH550-xxR-114A-2 R4 200
50 ACH550-xxR-143A-2 R6 200
60 ACH550-xxR-178A-2 R6 315
170M1372
2
or
170M2619
75 ACH550-xxR-221A-2 R6 315
100 ACH550-xxR-248A-2 R6 315
380… 480 Volt
Frame
Size
Drive Input Fuse Ratings
HP Identification
1
Amps
(600V)
Bussmann
Type
1/1.5 ACH550-xxR-03A3-4 R1 15 KTK-R-15
2 ACH550-xxR-04A1-4 R1 15 KTK-R-15
3 ACH550-xxR-06A9-4 R1 15 KTK-R-15
5 ACH550-xxR-08A8-4 R1 15 KTK-R-15
7.5 ACH550-xxR-012A-4 R1 15 KTK-R-15
10 ACH550-xxR-015A-4 R2 30 KTK-R-30
15 ACH550-xxR-023A-4 R2 30 KTK-R-30
20 ACH550-xxR-031A-4 R3 60 JJS-60
25 ACH550-xxR-038A-4 R3 60 JJS-60
30 ACH550-xxR-045A-4 R3 60 JJS-60
40 ACH550-xxR-059A-4 R4 100 JJS-100
50 ACH550-xxR-072A-4 R4 100 JJS-100
60 ACH550-xxR-078A-4 R4 100 JJS-100
75 ACH550-xxR-097A-4 R4 200
170M1370
2
or
170M2617
100 ACH550-xxR-125A-4 R5 200
125 ACH550-xxR-157A-4 R6 200
150 ACH550-xxR-180A-4 R6 315
170M1372
2
or
170M2619
200 ACH550-xxR-246A-4 R6 315
208… 240 Volt
Frame
Size
Drive Input Fuse Ratings
HP Identification
1
Amps
(600V)
Bussmann
Type
