Chapter 14 - Tightening Torques and Threaded Connections ABB
14-2 (4) 3BHS202077 ZAB E01 Rev. C ACS 6000 Maintenance Manual
Figure 14-2 Exploded View
1) not fitted on Etachrom 25-160/..., 32-160/...
2) not fitted
Table 14-3 List of Components
Item No. Description Item No. Description
101 Pump casing 68-3 Cover plate
163 Discharge cover 801 Flanged motor
182.2
2)
Pump foot 901.1/5 Hex. head bolt
210 Shaft 902.1 Stud
230 Impeller 903.1 Screwed plug
341 Drive lantern 914 Socket head cap screw
411.3 Joint ring 920.1-.4 Hex. nut
412.1 O-ring 930.1 Spring washer
433 Mechanical seal 940.2 Key
502.1/.2
1)
Casing wear ring 6B Casing drain
512 Taper lock ring
