can help you in selecting the breaker type when the supply network characteristics
are known.
WARNING!
Due to the inherent operating principle and construction of circuit breakers,
independent of the manufacturer, hot ionized gases can escape from the
breaker enclosure in case of a short-circuit. To ensure safe use, pay special
attention to the installation and placement of the breakers. Obey the
manufacturer’s instructions.
You can use the circuit breakers specified by ABB. You can also use other circuit
breakers with the drive if they provide the same electrical characteristics. ABB
does not assume any liability whatsoever for the correct function and protection
of the circuit breakers not specified by ABB. Furthermore, if the specifications
given by ABB are not obeyed, the drive can experience problems the warranty does
not cover.
Network SC
1)
Miniature circuit breaker
FrameACS180-04...
kAABB type
1-phase
U
n
= 208 ... 240 V
5S201P-B10NAR0-02A4-1
5S201P-B10NAR0-03A7-1
5S201P-B16NAR0-04A8-1
5S201P-B20NAR1-06A9-1
5S201P-B25NAR1-07A8-1
5S201P-B25NAR1-09A8-1
5S201P-B32NAR2-12A2-1
3-phase
U
n
= 208 ... 240 V
5S203P-Z6NAR0-02A4-2
5S203P-Z8NAR0-03A7-2
5S203P-Z10NAR0-04A8-2
5S203P-Z16NAR1-06A9-2
5S203P-Z16NAR1-07A8-2
5S203P-Z25NAR1-09A8-2
5S203P-Z32NAR2-15A6-2
5S203P-Z32NAR2-17A5-2
5S203P-Z50NAR3-25A0-2
Technical data 115
