Arrow keys (menu navigation and setting values)4
Stop key (when the drive is locally controlled)5
Start key (when the drive is locally controlled)6
Status LED:7
• Steady green: Normal operation
• Blinking green: Active warning
• Steady red: Active fault
• Blinking red: Active fault, set power to off to reset.
The user interface in brief:
• In the Home view, push the Back key to open the Options view.
• In the Home view, push the OK key to open the Menu .
• Navigate the views with the arrow keys.
• Push the OK key to open the highlighted setting or item.
• Use the left and right arrow keys to highlight a value.
• Use the up and down arrow keys to set a value.
• Push the Back key to cancel a setting or return to the previous view.
￭
Home view
The Home view shows the reading of one of three measured signals. Select the
page with the left and right arrow keys.
The status bar at the top of the Home view shows:
• The control location ( Loc for local control and Rem for remote control)
• The status icons
• The reference target value.
From the Home view, push the Back key to open the Options view and push the
OK key to open the Menu .
Adjust the current reference value with the up and down arrow keys.
Status icon
DescriptionAnimationIcon
Local Start/Stop enabledNone
StoppedNone
34 Operation principle and hardware description
