5. Install the new fan into the fan cover. Make sure that the air flow is in the correct
direction. The air flows in from the bottom of the drive and out from the top
of the drive.
6. Connect the fan power cable.
7. Carefully put the fan cover into position in the drive. Make sure that the fan
power cable is routed correctly.
8. Push the cover to lock into position.
Maintenance 93
