ABB ACSM1 Control Panel User Manual

Operation
21
Output mode
In the Output mode, you can:
• monitor actual values of up to three signals
• change the direction of the motor rotation
• set the speed, frequency, torque or position reference
• adjust the display contrast
• start, stop, change the direction and switch between local and remote control.
You get to the Output mode by pressing repeatedly.
The top right corner of the display shows the reference
value. The center can be configured to show up to three
signal values or bar graphs.
How to change the direction of the motor rotation
Step Action Display
1. If you are not in the Output mode, press repeatedly until you get there.
2. If the drive is in remote control (REM shown on the status line), switch to local
control by pressing . The display briefly shows a message about changing
the mode and then returns to the Output mode.
3. To change the direction from forward ( shown on the status line) to reverse (
shown on the status line), or vice versa, press .
EXIT
50 A
10 Hz
7 %10.
0.
49.
LOC
DIR
MENU00:00
30.00rpm
EXIT
50 A
10 Hz
7 %10.
0.
49.
REM
DIR
MENU
00:00
30.00rpm
LOC
REM
50 A
10 Hz
7 %10.
0.
49.
LOC
DIR
MENU
00:00
30.00rpm
DIR
