Operation
24
Parameters
In the Parameters option, you can:
• view and change parameter values
• start, stop, change the direction and switch between local and remote control.
How to select a parameter and change its value
Step Action Display
1. Go to the Main menu by pressing if you are in the Output mode, otherwise
by pressing repeatedly until you get to the Main menu.
2. Go to the Parameters option by selecting PARAMETERS on the menu with
keys and , and pressing .
3. Select the appropriate parameter group with keys and .
Press .
4. Select the appropriate parameter with keys and . The current
value of the parameter is shown below the selected parameter.
Press .
5. Specify a new value for the parameter with keys and .
Pressing the key once increments or decrements the value. Holding the key
down changes the value faster. Pressing the keys simultaneously replaces the
displayed value with the default value.
MENU
EXIT
PARAMETERS
FAULT LOGGER
TIME & DATE
EXIT ENTER
00:00
MAIN MENU 1
LOC
ENTER
01 ACTUAL VALUES
02 I/O VALUES
03 CONTROL VALUES
04 POS CTRL VALUES
06 DRIVE STATUS
EXIT
SEL00:00
PAR GROUPS 01
LOC
99 START-UP DATA
01 ACTUAL VALUES
02 I/O VALUES
03 CONTROL VALUES
04 POS CTRL VALUES
EXIT
SEL00:00
PAR GROUPS 99
LOC
SEL
9901 LANGUAGE
ENGLISH
9904 MOTOR TYPE
9906 MOT NOM CURRENT
9907 MOT NOM VOLTAGE
PARAMETERS
EXIT
EDIT
00:00
LOC
9901 LANGUAGE
9904 MOTOR TYPE
AM
9906 MOT NOM CURRENT
9907 MOT NOM VOLTAGE
PARAMETERS
EXIT
EDIT
00:00
LOC
EDIT
9904 MOTOR TYPE
PAR EDIT
AM
CANCEL SAVE
00:00
[0]
LOC
9904 MOTOR TYPE
PAR EDIT
PMSM
CANCEL SAVE
00:00
[1]
LOC
