Appendix
A1 Correspondence between variables and physical addresses
This paragraph describes the correspondence between the variables and their physical
memory addresses. This information is required for certain functions such as COPY, data
exchange between the CS31 system bus master and slave basic units.
The variable address is given by the segment and offset value.
These values are expressed in hexadecimal format.
H 0000 is the segment for all variables.
The correspondence between the variable and the segment is given in the following table:
Variables Physical addresses (Byte count)
E00,00...E00,07/E00,08...E00,15
E01,00...E01,07/E01,08...E01,15
E02,00...E02,07/E02,08...E02,15
E61,00...E61,07/ E61,08...E61,15
E62,00...E62,07/ E62,08...E62,15
E68,00....E68,15
H 1900/H 1901
H 1902/H 1903
H 1904/H 1905
H 197A/H 197B
H 197C/H 197D
H 1988/H 1989
M00,00....M00,07/M00,08...M00,15
M99,00...M99,15
M230,00...M230,15
M255,00...M255,15
H 1A00/H 1A01
H 1AC6/H 1AC7
H 1AC8/H 1AC9
H 1AFA/H 1AFB
A00,00....A00,07/ A00,08...A00,15
A01,00...A01,15
A02,00...A02,15
A61,00....A61,15
A62,00...A62,15
A68,00....A68,15
H 1B00/H 1B01
H 1B02/H 1B03
H 1B04/H 1B05
H 1B7A/H 1B7B
H 1B7C/H 1B7D
H 1B88/H 1B89
MW00,00
MW00,01
MW99,00
MW99,15
MW230,00
MW230,15
MW255,15
H 1C00
H 1C02
H 2860
H 287E
H 2880
H 289E
H 2BBE
