Technical specifications 3 – 16 Advant Controller AC 31 / Issued: 01.99
3
3.5.2 Digital central extensions specifications
The digital extension units are powered at 5 V by the basic unit or extensible remote unit to
which they are connected.
Warning: the extensions must not be connected or disconnected under power supply.
XI 16 E1 XO 08 R1 XC 08 L1 XK 08 F1 XO 16N1
Weight 220 g 220 g 220 g 220 g 220 g
Integrated digital inputs
- Number of inputs 16 - 8 configurable 4 -
- Isolateds inputs (test voltage) 1500 V a.c. - 1500 V a.c. 1500 V a.c. -
- Types of inputs PNP - PNP PNP -
- Input voltage:
nominal value
signal at 0 (IEC 1131-2)
signal at 1 (IEC 1131-2)
24 V d.c.
0 to + 5 V
+ 15 to + 30 V
- 24 V d.c.
0 to + 5 V
+ 15 to + 30 V
24 V d.c.
0 to + 5 V
+ 15 to + 30 V
-
- Input current at 24 V d.c. 4 mA - 4 mA 7 mA -
- Signal delay time 5 ms - 5 ms 5 ms -
- Cable length:
unshielded
shielded
300 m
500 m
-
-
300 m
500 m
300 m
500 m
-
-
Integrated outputs
- Number of outputs - 8 relays 8 transistors 4 relays 16 transistors
- Isolated outputs (test voltage) - 1500 Vrms
1 min
1500 V a.c.
1 min
1500 Vrms
1 min
1500 V a.c.
1 min
- Load current, under/channel:
24 V d.c.
alternate 24 to 230 V a.c.
-
-
2 A
2 A AC-1
0.5 A AC-15
0.5 A
-
2 A
2 A AC-1
0.5 A AC-15
0.5 A
-
- Total load current - 8 x 2 A 8 x 0.5 A 4 x 2 A 16 x 0.5 A
- Output leakage current -
< 200 µA < 200 µA
- Leakage voltage - 0.5 V to 500 mA
max.
0.5 V to 500 mA
max.
- Minimum load - 10 mA at
12 V d.c.
12 V 10 mA at
12 V d.c.
12 V
