34 Mechanical installation
Fastening methods
Fasten the cabinet to the floor with the clamps included along the edge of the cabinet
bottom.
Clamping
Floor clamping
Insert the clamps into the twin slots along the front and rear edges of the cabinet frame
body and fasten them to the floor with a M12 bolt. The recommended maximum distance
between the clamps in the front edge is 800 mm (31.5″).
Wall clamping
If floor mounting at the back is not possible, fasten the top of the cabinet to the wall with L-
brackets (not included in the delivery) bolted to the lifting bar fastening holes.
