Documents related to REL670 Identity number
Setting example 2, Setting example 1, 400 kV Long overhead power line with breaker-and-a-half CB arr. Mho
characteristic.
1MRK 506 291-WEN
Setting example 3, 230 kV Extremely long overhead power line, double bus, single CB arr. Quadrilaterial
characteristic.
1MRK 506 268-WEN
Setting example 4, 230 kV Extremely long overhead power line, double bus, single CB arr. Mho characteristic. 1MRK 506 292-WEN
Setting example 5, 132 kV Short overhead power line, double bus, single CB arr. Quadrilaterial characteristic. 1MRK 506 269-WEN
Setting example 6, 132 kV Short overhead power line, double bus, single CB arr. Mho characteristic. 1MRK 506 290-WEN
Setting example 7, 70 kV power line on a resonance earth system. Double bus, single breaker arrangement. 1MRK 506 293-WEN
Setting example 8, 400 kV long series compensated line. breaker-and-a-half arrangement. 1MRK 506 294-WEN
Connection and Installation components 1MRK 513 003-BEN
Test system, COMBITEST 1MRK 512 001-BEN
Accessories for IED 670 1MRK 514 012-BEN
Getting started guide IED 670 1MRK 500 080-UUS
SPA and LON signal list for IED 670, ver. 1.1 1MRK 500 083-WEN
IEC 61850 Data objects list for IED 670, ver. 1.1 1MRK 500 084-WEN
Generic IEC 61850 IED Connectivity package 1KHA001027-UEN
Protection and Control IED Manager PCM 600 Installation sheet 1MRS755552
Engineering guide IED 670 products 1MRK 511 179-UEN
More information can be found on
www.abb.com/substationautomation.
1.1.5 Revision notes
Revision
Description
C No functionality added. Changes made in content due to problem reports.
Section 1 1MRK506276-UUS B
Introduction
14
Operator's manual
