3.5 Mounting examples
Pos: 8.20 /Montage/A ktorik/Elektr. Schwenkantriebe/RHD250. ..4000/Befesti gungselemente @ 14\mod_1194 260025953_3101.doc @ 135681
3.5.1 Fastening elements
RHD250 RHD500
RHD800
RHD1250
RHD2500
RHD4000
clamping screws for
mech. limit stop
tightening torque: 79 Nm
(58 Lbf-ft)
95 Nm
(144 Lbf-ft)
670 Nm
(494 Lbf-ft)
670 Nm
(494 Lbf-ft)
lever clamping screw
tightening torque: 79 Nm
(58 Lbf-ft)
195 Nm
(144 Lbf-ft)
390 Nm
(288 Lbf-ft)
390 Nm
(288 Lbf-ft)
Mounting screw
(property class 8.8)
tensile strength: 12 mm
(0.47 inch)
18 mm
(0.71 inch)
20 mm
(0.78 inch)
20 mm
(0.78 inch)
tensile strength:
≥ 800 N/mm
2
(≥ 116032
pounds/square
inch)
≥ 800 N/mm
2
(≥ 116032
pounds/square
inch)
≥ 800 N/mm
2
(≥ 116032
pounds/square
inch)
≥ 800 N/mm
2
(≥ 116032
pounds/square
inch)
Yield strength
≥ 640 N/mm
2
(≥ 93550
pounds/square
inch)
≥ 640 N/mm
2
(≥ 93550
pounds/square
inch)
≥ 640 N/mm
2
(≥ 93550
pounds/square
inch)
≥ 640 N/mm
2
(≥ 93550
pounds/square
inch)
