Technical data

42/68-165-EN RHD250 ... 4000 33

Pos: 18.1 /Überschri ften/1/S - U/Technische D aten @ 0\mod_113290457 4837_3101.doc @ 3169

8 Technical data

Pos: 18.2 /Überschri ften/1.1/1-spa ltig/A - C/Allgemeine Dat en @ 0\mod_1140622753015_ 3101.doc @ 3177

8.1 General information

Pos: 18.3 /Technische Dat en / Datenblatt/Akt orik/Antriebe/Sc hwenkantriebe/El. Schwenkantrieb RHD 250 (C ontrac)/Allgemeine Da ten @ 5\mod_1152865531468_ 3101.doc @ 34714

RHD250-10

Operating mode S9 - 100%; stallproof acc. to IEC 60034-1 / EN 60034-1

Protection class IP 66

Humidity

≤ 95% average; condensation not permitted

Ambient temperature -10 … 65° C (15 … 150° F)

-30 … 50° C (-20 … 130° F)

-1 … 85° C (30 … 185° F)

Mounting position Any position; preferably IMB 3 acc. to IEC 60034-7 / EN 60034-7

Coating 2-layer component epoxy (RAL 9005; black)

Anti-condensation heater Motor: Directly power feed from Contrac electronic unit.

Signal space: Separate heating resistor; separate power supply or power feed from

Contrac electronic unit.

Electrical connection Plug with crimp snap-in contacts or terminals.

Connecting cable electronics – actuator optionally (see ordering information of electronics).

Power supply for motor and sensors Only via Contrac electronic unit (see data sheet of electronic unit).

Pos: 18.4 /Überschri ften/1.1/1-spa ltig/S - U/Technische Date n RHD250 @ 14\mod_11942658 07718_3101.doc @ 135943

8.2 Technical data RHD250

Pos: 18.5 /Technische Dat en / Datenblatt/Akt orik/Antriebe/Sc hwenkantriebe/El. Schwenkantrieb RHD 250 (C ontrac)/Regelantri eb @ 5\mod_1152865570078_ 3101.doc @ 34966

Model RHD250-10

Rated torque 250 Nm (200 lbf-ft), adjustable to 0.5; 0.75

or 1x rated torque

Starting torque 1.2 x rated torque (break-away torque in

end positions for short time 2 x rated

torque)

Rated time for 90°;

adjustable

10 … 900 s

Operating speed;

adjustable

(9.0 … 0.1°/s)
