1.4.2 Name plate
Pos: 4.12 /Sicher heit/Aktorik/Allge mein/Typenschild @ 14\ mod_1194257536484_3101. doc @ 135582
M00365
Antrieb / Actu ator: CONTRAC ....
F-Nr./No NL
M = Jahr/Year
CE
t= IP66
min......max. ....... max. .........
Öl
Elektronik/Electronics
/ Oil:
ABB Automation
D-32425 Minden
Made in Germany
1
2
3
4
5
6
7
8
9
10
Fig. 1
1 Complete model name
2 Fabrication no./ NL no. (no. of non-
standard version)
3 Output torque / Year of manufacture
4 Permissible ambient temperature and
protection class / CE mark
5 min./max. crank angle and max.
actuating speed
6 Filled oil types
7 Associated Contrac electronic unit
8 Free
9 Free
10 Free for customer-specific entry
Pos: 4.13 /Sicher heit/Aktorik/Allge mein/Pflichten des Be treibers @ 10\mod_118172 3170562_3101.doc @ 105157
1.5 Operator liability
The operators must strictly observe the applicable national regulations in their countries with
regards to installation, function tests, repairs, and maintenance of electrical devices.
Pos: 4.14 /Sicher heit/Allgemein/Organis atorische Maßnah men/Qualifikation des Per sonals @ 0\mod_1129728 800194_3101.doc @ 3247
1.6 Personnel qualification
The installation, commissioning and maintenance of the device may only be carried out through
trained specialist personell authorized by the plant operator. The specialist personnel must have
read and understood the manual and comply with its instructions.
