Technical data
42/68-165-EN RHD250 ... 4000 35
Pos: 18.12 /Überschri ften/1.1/1-spa ltig/S - U/Technische Dat en RHD4000 @ 14\mod_119426 5956640_3101.doc @ 136012
8.5 Technical data RHD4000
Pos: 18.13 /Technische Da ten / Datenblatt/Ak torik/Antriebe/Sc hwenkantriebe/El. Schwenkantrieb RHD 4000 (C ontrac)/Regelantr ieb @ 5\mod_1154413133 609_3101.doc @ 36376
Model RHD4000-10 RHD4000-40
Rated torque 4000 Nm (3000 lbf-ft)
(adjustable to 0.5 / 0.75 or 1x rated torque)
Starting torque 1.2 x rated torque (break-away torque in end positions for short time 2 x rated torque)
Rated time for 90° 10 … 900 s 40 … 900 s
Operating speed, adjustable 9.0 … 0.1 °/s 2.25 … 0.1 °/s
Operating angle Typically 90° (min. 35°, max. 270°). See instructions for limited operating angle if actuator is equipped with
lever and limit stop.
Weight approx. 270 kg (595 lb) approx. 265 kg (584 lb)
Related electronics
For field installation:
For rack installation:
Model EBN861
1)
Model EBS862
2)
Model EBN853
3)
Model EBS852
4)
Motor type MC 100 BA MC 90 BA
Sensors Position and temperature sensor always available.
1)
Data sheet EBN861:10/68-8.22
2)
Data sheet EBS862:10/68-8.25
3)
Data sheet EBN853: 10/68-8 27
4)
Data sheet EBS852: 10/68-8 24
