ABB | SACE Emax 2
Ekip Touch - Interface and menus
1 - Presentation of interface
8 | © 2023 ABB | 1SDH001316R1002 - ECN000297030
Ekip Touch - Interface and menus
1 - Presentation of interface
Functions
The Ekip Touch operator interface allows you to:
• display signals and measurements of the functions in progress or recorded events
• configure the parameters, the protections present and other functions of the unit
• Set parameters for the connected accessory modules
• perform tests
Components
The Ekip Touch interface includes a touchscreen, short-cut push-buttons, status leds and a service
connector for certain external accessories:
Figure 2
Pos. Description
A Single-touch color touchscreen display
B LED Power
C LED Warning
D LED Alarm
E HOME push-button
F iTEST push-button
G Service connector
