20 | © 2023 ABB | 1SDH001316R1002 - ECN000297030 Protections
4 - Voltage Advanced protections
List
The Advanced Voltage protections, available by default for the Ekip G Touch and Ekip G Hi-Touch models and configurable in the remaining
models as additional SW package, are:
Name Type of protection Threshold Time Additional functions
(3)
S(V) Short-circuit with voltammetric control Mode, Trip enable, Block
S2(V)
(1)
Short-circuit with voltammetric control Mode, Trip enable, Block
RV
(2)
Residual voltage Trip enable, Block
Further details about the protections are given in document 1SDH001330R1002.
(1)
S2(V) protection is not available by default with Ekip G Touch. However, it can be integrated by requesting the relative SW package
(2)
available for 4P or 3P circuit-breakers configured with external neutral voltage
(3)
Block configuration available via Ekip Connect
Summary table
ABB
ANSI
(6)
Threshold
(7)(8)
Tolerance
threshold
Time
Calculation
formula t
t
(4)
Tolerance t
t
(5)
S(V) 51V
I20 = 0,6...10 In step = 0,1 In
(9)
;
Ul = 0,2...1 Un step = 0,01 Un
(9)
;
Uh = 0,2...1 Un step = 0,01 Un
(9)
;
Ks = 0,1…1 step = 0,01
(9)
± 10 %
t20 = 0,05...30 s
Step = 0,01 s
t
t
= t20
The best of the two values: ± 10% or ±
40 ms (for set time < 5 s) / ± 100 ms
(for set time ≥ 5 s)
S2(V) 51V
I21 = 0,6...10 In step = 0,1 In
(10)
;
Ul2 = 0,2...1 Un step = 0,01 Un
(10)
;
Uh2 = 0,2...1 Un step = 0,01 Un
(10)
;
Ks2 = 0,1…1; step = 0,01
(10)
± 10 %
t21 = 0,05...30 s
Step = 0,01 s
t
t
= t21
The best of the two values: ± 10% or ±
40 ms (for set time < 5 s) / ± 100 ms
(for set time ≥ 5 s)
RV 59N
U22 = 0,05...0,5 Un Step = 0,001
Un
± 5 %
(11)
t22 = 0,05...120 s
Step = 0,01 s
t
t
= t22
The best of the two values: ± 10% or ±
40 ms (for set time < 5 s) / ± 100 ms
(for set time ≥ 5 s)
(4)
calculation of t
t
is valid for values which have exceeded the trip threshold of the protection
(5)
tolerance values valid with Trip unit supplied at full rate or by auxiliary power supply, trip time ≥ 100 ms, temperature and current values
within operating limits; the tolerance value is ± 20% if the conditions are not guaranteed
(6)
ANSI / IEEE C37-2 codification
(7)
S(V) protection: in the Linear mode, the current trip threshold for voltage values between Ul and Uh is calculated by performing linear
interpolation between thresholds Uh and I20 (first point of the line) and Ul and Ks * I20 (second point of the line). I
threshold
= [I20 * (1 - Ks) *
(U
measured
- Uh)] / (Uh - Ul) + I20
(8)
S2(V) protection: in the Linear mode, the current trip threshold for voltage values between Ul2 and Uh2 is calculated by performing
linear interpolation between thresholds Uh2 and I21 (first point of the line) and Ul2 and Ks2 * I21 (second point of the line). I
threshold
= [I21 *
(1 - Ks2) * (U
measured
– Uh2)] / (Uh2 - Ul2) + I21
(9)
the threshold Ks setting must ensure the following limitation: Ks * I20 ≥ 0.6 In; parameter Uh is available in the Linear mode; the setting
must comply with the following limitation: Uh > Ul
(10)
the threshold Ks2 setting must ensure the following limitation: Ks2 * I21 ≥ 0.6 In; parameter Uh2 is available in the Linear mode; the
setting must comply with the following limitation: Uh2 > Ul2
(11) tolerance values valid with Trip unit supplied at full rate or by auxiliary power supply, trip time ≥ 100 ms, temperature and current
values within operating limits; the tolerance value is ± 10% if the conditions are not guaranteed
