Trip unit Overview
1 - General characteristics
6 | © 2023 ABB | 1SDH001316R1002 - ECN000297030
Trip unit Overview
1 - General characteristics
Main functions
SACE Emax 2 can be configured using the Ekip Touch trip unit, which is available in several versions and
able to provide, protection, measurement and signalling functionalities.
Emax 2 can be provided with mechanical, electronic and testing accessories, and is supported by many
different types of software and applications enabling the functions of the Trip unit and circuit-breaker to
be expanded.
Detailed information is available in manual 1SDH001330R1001. 1SDH001330R1002.
Default functions and
extensions
Every Ekip Touch module has default measurement and protection functions, which can be extended with
the aid of additional software packages.
The extensions (additional SW packages) can be pre-engineered when the circuit-breaker is ordered or at
a later date (in this case, via ABB Ability Marketplace
TM
Overview
Model Ekip Touch
Ekip Hi-
Touch
Ekip G
Touch
Ekip G Hi-
Touch
Versions LSI, LSIG LSI, LSIG LSIG LSIG
Standard protections X X X X
Voltage protections O
(1)
X X
(3)
X
Voltage advanced protections O
(1)
O X
(3)
X
Frequency protections O
(1)
X X
(3)
X
Power protections O
(1)
X
(3)
X
(3)
X
ROCOF protections O
(1)
O O X
Adaptive protections O X O X
Standard Measurements X X X X
Measuring Measurements O X X X
Class 1 Power & Energy Metering O
(2)
X O X
Datalogger O
(1)
X X X
Network Analyzer O
(1)
X O X
X = Available by default; O = Optional
(1)
Configurable if Measuring Measurements package is present
(2)
Only available at the time circuit-breaker is ordered
(3)
Certain protections of the complete package are available by default; the remaining ones can be
activated on request
Description
Lists of the main characteristics of the protections and measurements of each package are given in the
next chapters.
A description of the Datalogger and Network Analyzer functions is available in manual 1SDH001330R1002.
