ABB SACE Emax 2 Instructions

ABB | SACE Emax 2
Protections
9 - Additional protections and functions
24 | © 2023 ABB | 1SDH001316R1002 - ECN000297030
9 - Additional protections and functions
Additional protections
Some protections have additional functions which extend their characteristics and performance:
Name Description Protections
Thermal
Memory
Reduced trip time in the case of TRIPs within brief
intervals (protection against cable overheating)
L, S
Zone
selectivity
Additional parameters for managing TRIP
commands between circuit-breakers equipped
with the same function
S, S2, G, D, Gext, MDGF
Blocks
Blocking of protection on the basis of
programmable events
S, I, G, MCR, S2, D, S(V), S2(V), UV,
OV, VU, UV2, OV2, UP, OP, RP, RQ,
OQ, RV, UF, OF, UF2, OF2, ROCOF,
Gext, MDGF
Startup
Different threshold of the protection for a
limited time, with activation on the basis of a
programmable monitoring threshold
S, I, G, S2, D, UP, Gext, MDGF
Additional protections
Installation of certain accessories allows the additional protections to be activated:
Name Type of protection
Th-
reshold
Time
Fun-
ction
Additional functions
Gext
Earth fault with current
reading by S.G.R.
external sensor
Trip enable, Zone Selectivity,
Startup enable, Locking, Pre-alarm
threshold
Rc
Residual current with
corrent reading by
external toroid Rc
Synchrocheck
Synchronism between
two independent
voltage sources or
energizing of a busbar
not active
MDGF
Earth fault with current
reading by MDGF
external sensor
Trip enable, Zone Selectivity,
Startup enable, Locking, Pre-alarm
threshold
Further details about the protections are given in document 1SDH001330R1002.
Programmable Functions and
Commands
Ekip Touch has eight programmable commands, which activate on the basis of signals or events. Each
command allows the activation function and event monitoring time to be programmed.
Name Description Menu path
External Trip Sends a TRIP command
Advanced - FunctionsRESET Trip TRIP signal reset
Activate SET B Changes the protections set, from Set A to Set B
Energy RESET Resets the energy meters Measurements - Energy
Command YO
Sends a command to opening coil YO
Settings - Functions
Command YC
Sends a command to closing coil YC
LOCAL Switch On
Changes the configuration, from Remote to
Local
Settings - Modules
- Functions
Signaling RESET
Reset the contacts of the signalling modules

ABB SACE Emax 2 Specifications

General

Type	Air circuit breaker
Rated Current	800 A to 6300 A
Breaking Capacity	Up to 150 kA at 415 V AC
Frequency	50/60 Hz
Number of Poles	3, 4
Installation	Fixed or withdrawable
Standards	IEC 60947-2
Trip Unit	Ekip Touch, Ekip Hi-Touch
Communication	Modbus, Profibus, Ethernet
