2 - Standard Protections
List
The Standard protections available for all Ekip Touch models, are:
Name Type of protection
Th-
reshold
Time
Fun-
ction
Additional functions
(6)
L Overloads with inverse long-time delay Thermal memory, Pre-alarm threshold
S Short-circuit with adjustable delay
Trip enable, Zone Selectivity, Thermal
Memory, Startup enable, Lock
S2 Short-circuit with adjustable delay
Trip Enable, Zone Selectivity, Startup
enable, Lock
I
(3)
Instantaneous short-circuit Startup enable, Lock
G
(2)(5)
Earth fault with adjustable delay
Trip enable, Zone Selectivity, Startup
enable, Locking, Pre-alarm threshold
MCR
(4)
Instantaneous short-circuit on circuit-
breaker closing
Monitoring period, Locking
2I
Instantaneous short-circuit
programmable
Zone selectivity, activation function and
mode, Delay ON/OFF
IU Current unbalance
Trip enable, Algorithm
Neutral Different protection on neutral phase
T Abnormal temperatures
Trip enable
Iinst
(1)
Instantaneous short-circuit
Harmonic
distortion
(7)
Distorted waveforms
Hardware Trip Internal connection errors
Current thresholds
(7)
Control thresholds exceeded Direction of current flow
Further details about the protections are given in document 1SDH001330R1002.
(1)
protection cannot be deactivated; its trip parameters are set by ABB and cannot be edited
(2)
not available with LSI version of Trip unit
(3)
can be activated with protection MCR = Disable
(4)
can be activated with protection I = Disable
(5)
if the presence of sensor S.G.R. is activated, the submenu of protection G will be replaced by that of protection Gext, in the Advanced
menu; with Trip unit models Ekip Hi-Touch and Ekip G Hi-Touch, the two protections are available at the same time
(6)
Thermal memory available with curve t=k/I
2
; Zone selectivity available with curve t=k; Block configuration available via Ekip Connect
(7)
the protections do not handle the TRIP, just signaling

ABB SACE Emax 2 Specifications

General

Type	Air circuit breaker
Rated Current	800 A to 6300 A
Breaking Capacity	Up to 150 kA at 415 V AC
Frequency	50/60 Hz
Number of Poles	3, 4
Installation	Fixed or withdrawable
Standards	IEC 60947-2
Trip Unit	Ekip Touch, Ekip Hi-Touch
Communication	Modbus, Profibus, Ethernet
